9311-60 Series
Manufacturer: McGill Microwave Systems
Beta
⌘K
CONN SMP PLUG STR 50OHM EDGEMNT
| Part | Body Finish | Center Contact Plating | Dielectric Material | Mating Cycles | Body Material | Number of Ports | Connector Type | Mounting Type | Fastening Type | Center Contact Material | Features | Shield Termination | Connector Style | Frequency - Max | Impedance | Housing Color | Contact Termination | Color | Features - Positions | Accessory Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 McGill Microwave Systems | Gold | Gold | Polytetrafluoroethylene (PTFE) | 1000 cycles | Stainless Steel | 4 | Male Pin Plug | Board Edge End Launch | Snap-On | Beryllium Copper | Smooth Bore | Solder | SMP | 26.5 GHz | 50 Ohm | Gold | Solder | |||
 McGill Microwave Systems | Gold | Gold | Polytetrafluoroethylene (PTFE) | 100 cycles | Stainless Steel | 4 | Male Pin Plug | Board Edge End Launch | Snap-On | Beryllium Copper | Full Detent | Solder | SMP | 26.5 GHz | 50 Ohm | Gold | Solder | |||
 McGill Microwave Systems | Gold | Gold | Polytetrafluoroethylene (PTFE) | 500 cycles | Stainless Steel | 2 | Male Pin Plug | Board Edge End Launch | Snap-On | Beryllium Copper | Limited Detent | Solder | SMP | 26.5 GHz | 50 Ohm | Gold | Solder | |||
 McGill Microwave Systems | Gold | Gold | Polytetrafluoroethylene (PTFE) | 1000 cycles | Stainless Steel | 4 | Male Pin Plug | Board Edge End Launch | Snap-On | Beryllium Copper | Smooth Bore | Solder | SMP | 26.5 GHz | 50 Ohm | Gold | Solder | |||
 McGill Microwave Systems | Gold | Gold | Polytetrafluoroethylene (PTFE) | 100 cycles | Stainless Steel | 4 | Male Pin Plug | Board Edge End Launch | Snap-On | Beryllium Copper | Full Detent | Solder | SMPM | 65 GHz | 50 Ohm | Gold | Solder | |||
 McGill Microwave Systems | Stainless Steel | SMPM | Silver | 10 positions | Housing Module | |||||||||||||||
McGill Microwave Systems | Gold | Gold | Polytetrafluoroethylene (PTFE) | 500 cycles | Stainless Steel | 4 | Male Pin Plug | Board Edge End Launch | Snap-On | Beryllium Copper | Limited Detent | Solder | SMP | 26.5 GHz | 50 Ohm | Gold | Solder | |||
 McGill Microwave Systems | Gold | Gold | Polytetrafluoroethylene (PTFE) | Stainless Steel | 4 | Male Pin Plug | Board Edge End Launch | Snap-On | Beryllium Copper | Full Detent | Solder | SMPM | 65 GHz | 50 Ohm | Gold | Solder | ||||
 McGill Microwave Systems | Gold | Gold | Polytetrafluoroethylene (PTFE) | 100 cycles | Stainless Steel | 2 | Male Pin Plug | Board Edge End Launch | Snap-On | Beryllium Copper | Full Detent | Solder | SMP | 26.5 GHz | 50 Ohm | Gold | Solder | |||
 McGill Microwave Systems | Gold | Gold | Polytetrafluoroethylene (PTFE) | 1000 cycles | Stainless Steel | 2 | Male Pin Plug | Board Edge End Launch | Snap-On | Beryllium Copper | Smooth Bore | Solder | SMP | 26.5 GHz | 50 Ohm | Gold | Solder |
