DSEI2X61 Series

Pwr Diode Disc-FRED SOT-227B (minibloc)

Catalog

Pwr Diode Disc-FRED SOT-227B (minibloc)

Part	Package / Case	Voltage - DC Reverse (Vr) (Max)	Current - Average Rectified (Io) (per Diode)	Speed - Fast Recovery (Maximum)	Speed - Fast Recovery (Minimum)	Package Name	Technology	Current - Reverse Leakage	Operating Temperature - Junction (Min)	Operating Temperature - Junction (Max)	Mounting Type	Reverse Recovery Time (trr)	Diode Count	Diode Configuration	Voltage - Forward (Vf) (Max)
LITTELFUSE DSEI2X61-12B	miniBLOC SOT-227-4	1200 V	52 A	500 ns	200 mA	SOT-227B	Standard	2.2 mA	-40 °C	150 °C	Chassis Mount	60 ns	2	Independent	2.5 V
LITTELFUSE DSEI2X61-10B	miniBLOC SOT-227-4	1 kV	60 A	500 ns	200 mA	SOT-227B	Standard	3 mA	-40 °C	150 °C	Chassis Mount	50 ns	2	Independent	2.3 V
LITTELFUSE DSEI2X61-06P	ECO-PAC1	600 V	60 A	500 ns	200 mA	ECO-PAC1	Standard	200 µA			Chassis Mount	50 ns	2	Independent	1.8 V
LITTELFUSE DSEI2X61-12P	ECO-PAC1	1200 V	52 A	500 ns	200 mA	ECO-PAC1	Standard	2.2 mA	-40 °C	150 °C	Chassis Mount	60 ns	2	Independent	2.5 V
LITTELFUSE DSEI2X61-04C	miniBLOC SOT-227-4	400 V	60 A	500 ns	200 mA	SOT-227B	Standard	200 µA	-40 °C	150 °C	Chassis Mount	50 ns	2	Independent	1.8 V
LITTELFUSE DSEI2X61-06C	miniBLOC SOT-227-4	600 V	60 A	500 ns	200 mA	SOT-227B	Standard	200 µA	-40 °C	150 °C	Chassis Mount	50 ns	2	Independent	1.8 V

Catalog

Pwr Diode Disc-FRED SOT-227B (minibloc)

Description

The Fast Dual Diode series offers various packages and breakdown voltages up to 1200V. Utilizing FRED dies enables fast reverse recovery capabilities.
