AD8000 Series

Catalog

IC OPAMP CFA 1 CIRCUIT 8LFCSP

Part	Current - Input Bias	-3db Bandwidth	Package / Case	Slew Rate	Number of Circuits	Current - Output / Channel	Voltage - Supply Span (Min)	Amplifier Type	Package Width	Package Name	Package Length	Current - Supply	Operating Temperature (Max)	Operating Temperature (Min)	Voltage - Input Offset	Mounting Type	Voltage - Supply Span (Max)	Package Features
Analog Devices Inc./Maxim Integrated AD8000YCPZ-R2	5 µA	1.35 GHz	8-WFDFN Exposed Pad CSP	4100 V/µs	1	100 mA	4.5 V	Current Feedback	3 mm	8-LFCSP	3 mm	13.5 mA	125 °C	-40 °C	1 mV	Surface Mount	12 V
Analog Devices Inc./Maxim Integrated AD8000YRDZ-REEL7	5 µA	1.58 GHz		4100 V/µs	1	100 mA	4.5 V	Current Feedback	3.9 mm	8-SOIC 8-SOIC-EP	0.154 in	13.5 mA	125 °C	-40 °C	1 mV	Surface Mount	12 V	Exposed Pad
Analog Devices Inc./Maxim Integrated AD8000YCPZ-REEL	5 µA	1.35 GHz	8-WFDFN Exposed Pad CSP	4100 V/µs	1	100 mA	4.5 V	Current Feedback	3 mm	8-LFCSP	3 mm	13.5 mA	125 °C	-40 °C	1 mV	Surface Mount	12 V
Analog Devices Inc./Maxim Integrated AD8000YCPZ-REEL7	5 µA	1.35 GHz	8-WFDFN Exposed Pad CSP	4100 V/µs	1	100 mA	4.5 V	Current Feedback	3 mm	8-LFCSP	3 mm	13.5 mA	125 °C	-40 °C	1 mV	Surface Mount	12 V
Analog Devices Inc./Maxim Integrated AD8000YRDZ	5 µA	1.58 GHz		4100 V/µs	1	100 mA	4.5 V	Current Feedback	3.9 mm	8-SOIC 8-SOIC-EP	0.154 in	13.5 mA	125 °C	-40 °C	1 mV	Surface Mount	12 V	Exposed Pad
