ADL5521 Series
Manufacturer: Analog Devices Inc./Maxim Integrated
Beta
⌘K
RF DEVELOPMENT TOOLS EVALUATION BOARD FOR ADL5521
| Part | Supplied Contents | For Use With/Related Products | Contents | Utilized IC / Part | Frequency (Min) | Frequency (Max) | Type | Package / Case | Voltage - Supply (Maximum) | Voltage - Supply (Minimum) | Mounting Type | Noise Figure | Test Frequency | Gain | RF Type | Package Name | Package Length | Package Width | Current - Supply | P1dB |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Analog Devices Inc./Maxim Integrated | Board(s) | ADL5521 | Board | ADL5521 | 400 MHz | 4 GHz | Amplifier | |||||||||||||
 Analog Devices Inc./Maxim Integrated | 400 MHz | 4 GHz | 8-VFDFN Exposed Pad CSP | 5 V | 3 V | Surface Mount | 0.8 dB | 900 MHz | 20.8 dB | General Purpose | 8-LFCSP-VD | 3 mm | 3 mm | 60 mA | 21.8 dBm |
