NBB10 Series
Manufacturer: Pepperl+Fuchs, Inc.
Beta
⌘K
INDUCTIVE PROXIMITY SENSOR, BASIC SERIES, 10 MM, CYLINDRICAL, PNP, 10 TO 30 VDC, CONNECTOR
| Part | Material - Body | Sensor Type | Shielding | Operating Temperature (Min) | Operating Temperature (Max) | Sensing Distance | Package / Case | Ingress Protection | Termination Style | Voltage - Supply (Minimum) | Voltage - Supply (Maximum) | Output Type | Indicator |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Pepperl+Fuchs, Inc. | Nickel-Plated Brass | Inductive | Unshielded | -40 °C | 70 °C | 0.394 " | Cylinder Threaded - M30 | IP67 | Connector | 10 VDC | 30 VDC | 4-Wire NO NPN-NC | LED |
 Pepperl+Fuchs, Inc. | |||||||||||||
 Pepperl+Fuchs, Inc. | Nickel-Plated Brass | Inductive | Unshielded | -25 °C | 70 °C | 0.394 " | Cylinder Threaded - M30 | IP67 | Cable | 20 VDC | 253 V | 2-Wire SCR-NO | LED |
 Pepperl+Fuchs, Inc. | Nickel-Plated Brass | Inductive | Unshielded | -25 °C | 70 °C | 0.394 " | Cylinder Threaded - M30 | IP67 | Cable | 10 VDC | 30 VDC | 3-Wire PNP-NO | LED |
 Pepperl+Fuchs, Inc. | |||||||||||||
 Pepperl+Fuchs, Inc. | Nickel-Plated Brass | Inductive | Unshielded | -25 °C | 70 °C | 0.394 " | Cylinder Threaded - M30 | IP67 | Cable | 10 VDC | 30 VDC | 4-Wire NO NPN-NC | LED |
 Pepperl+Fuchs, Inc. | Nickel-Plated Brass | Inductive | Unshielded | -25 °C | 70 °C | 0.394 " | Cylinder Threaded - M30 | IP67 | Cable | 5 V | 60 V | 2-Wire SCR-NO | LED |
 Pepperl+Fuchs, Inc. | Nickel-Plated Brass | Inductive | Unshielded | -25 °C | 70 °C | 0.394 " | Cylinder Threaded - M30 | IP67 | Cable | 10 VDC | 30 VDC | 3-Wire PNP-NO | LED |
 Pepperl+Fuchs, Inc. | Nickel-Plated Brass | Inductive | Unshielded | -25 °C | 70 °C | 0.394 " | Cylinder Threaded - M30 | IP67 | Connector | 20 VDC | 253 V | 2-Wire SCR-NO | LED |
Pepperl+Fuchs, Inc. | Nickel-Plated Brass | Inductive | Unshielded | -40 °C | 70 °C | 0.394 " | Cylinder Threaded - M30 | IP67 | Connector | 10 VDC | 30 VDC | 3-Wire PNP-NO | LED |
