CMB Pro9 Series

Catalog

WHITE LEDS XLAMP CMB LED WHITE PRO9 WHITE 40H

Part	Lens Type	Size / Dimension Width	Size / Dimension Length	Type	Color	Voltage - Forward (Vf) (Typ)	Configuration	Temperature - Test	CCT (K)	CCT Description	Lumens/Watt	Light Emitting Surface (LES) Diameter	Luminous Flux (Typical)	Viewing Angle	Height	Current - Test	CRI (Color Rendering Index)	Current - Max
CreeLED, Inc. CMB1825-0000-00PN0Z0A40H	Flat	17.85 mm	17.85 mm	Chip On Board (COB)	Neutral White	34 V	Square	85 °C	4000 K	2-Step MacAdam Ellipse	150 lm/W	12 mm	3576 lm	115 °	1.75 mm	700 mA	95	1.8 A
CreeLED, Inc. CMB1306-0000-00PN0U0A30U	Flat	13.35 mm	13.35 mm	Chip On Board (COB)	Warm White	33.3 V	Square	85 °C	3000 K	3-Step MacAdam Ellipse	141 lm/W	6 mm	933 lm	115 °	1.75 mm	200 mA	90	600 mA
CreeLED, Inc. CMB1840-0000-00PN0U0A35G	Flat	17.85 mm	17.85 mm	Chip On Board (COB)	Warm White	34.4 V	Square	85 °C	3500 K	3-Step MacAdam Ellipse	155 lm/W	14 mm	5854 lm	115 °	1.75 mm	1.1 A	90	2.4 A
CreeLED, Inc. CMB2550-0000-00PN0Z0A30H	Flat	23.85 mm	23.85 mm	Chip On Board (COB)	Warm White	34 V	Square	85 °C	3000 K	2-Step MacAdam Ellipse	152 lm/W	19 mm	7247 lm	115 °	1.75 mm	1.4 A	95	3.6 A
CreeLED, Inc. CMB1510-0000-00PN0Z0A27H	Flat	15.85 mm	15.85 mm	Chip On Board (COB)	Warm White	34 V	Square	85 °C	2700 K	2-Step MacAdam Ellipse	141 lm/W	9 mm	1675 lm	115 °	1.75 mm	350 mA	95	900 mA
CreeLED, Inc. CMB1306-0000-00PF0U0A30H	Flat	13.35 mm	13.35 mm	Chip On Board (COB)	Warm White	16.65 V	Square	85 °C	3000 K	2-Step MacAdam Ellipse	150 lm/W	6 mm	1002 lm	115 °	1.75 mm	400 mA	90	1.2 A
CreeLED, Inc. CMB1825-0000-00PN0U0A35G	Flat	17.85 mm	17.85 mm	Chip On Board (COB)	Warm White	34 V	Square	85 °C	3500 K	3-Step MacAdam Ellipse	158 lm/W	12 mm	3769 lm	115 °	1.75 mm	700 mA	90	1.8 A
CreeLED, Inc. CMB1825-0000-00PN0Z0A40H	Flat	17.85 mm	17.85 mm	Chip On Board (COB)	Neutral White	34 V	Square	85 °C	4000 K	2-Step MacAdam Ellipse	150 lm/W	12 mm	3576 lm	115 °	1.75 mm	700 mA	95	1.8 A
CreeLED, Inc. CMB2550-0000-00PN0Z0A40H	Flat	23.85 mm	23.85 mm	Chip On Board (COB)	Neutral White	34 V	Square	85 °C	4000 K	2-Step MacAdam Ellipse	152 lm/W	19 mm	7239 lm	115 °	1.75 mm	1.4 A	95	3.6 A
CreeLED, Inc. CMB2550-0000-00PN0U0A30H	Flat	23.85 mm	23.85 mm	Chip On Board (COB)	Warm White	34 V	Square	85 °C	3000 K	2-Step MacAdam Ellipse	158 lm/W	19 mm	7513 lm	115 °	1.75 mm	1.4 A	90	3.6 A
