ADA4097-2 Series
Manufacturer: Analog Devices Inc./Maxim Integrated
Beta
⌘K
50 V, 130 KHZ, 32.5 ΜA PER CHANNEL, ROBUST, OVER-THE-TOP, PRECISION OP AMP
| Part | Gain Bandwidth Product | Slew Rate | Current - Supply | Voltage - Supply Span (Max) | Number of Circuits | Package Name | Package Length | Package Width | Output Type | Amplifier Type | Package / Case | Current - Input Bias | Voltage - Supply Span (Min) | Voltage - Input Offset | Operating Temperature (Max) | Operating Temperature (Min) | Current - Output / Channel | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Analog Devices Inc./Maxim Integrated | 130 kHz | 0.1 V/µs | 42 µA | 50 V | 2 | 10-LFCSP | 3 mm | 3 mm | Rail-to-Rail | Voltage Feedback | 10-WFDFN Exposed Pad CSP | 100 pA | 3 V | 20 µV | 125 °C | -40 °C | 45 mA | Surface Mount |
