ADG936 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

BOARD EVALUATION FOR ADG936

Part	For Use With/Related Products	Supplied Contents	Utilized IC / Part	Frequency	Contents	Type	Impedance	Package Length	Package Name	Package Width	Frequency Range (Min)	Frequency Range (Max)	RF Type	Isolation	IIP3	Topology	Insertion Loss	Mounting Type	Voltage - Supply (Minimum)	Voltage - Supply (Maximum)	Circuit Type	Circuit Count	Package / Case	P1dB	Operating Temperature (Min)	Operating Temperature (Max)	Test Frequency	Circuit	Features
Analog Devices Inc./Maxim Integrated EVAL-ADG936EBZ	ADG936	Board(s)	ADG936	1 GHz	Board	SPDT Switch
Analog Devices Inc./Maxim Integrated ADG936BCPZ							50 Ohm	4 mm	20-LFCSP	4 mm	0 Hz	2 GHz	General Purpose	36 dB	32 dBm	Absorptive	0.9 dB	Surface Mount	1.65 V	2.75 V	SPDT	2	20-WFQFN Exposed Pad CSP	16 dBm	-40 °C	85 °C	1 GHz
Analog Devices Inc./Maxim Integrated ADG936BRU-R							50 Ohm	0.173 in	20-TSSOP	4.4 mm	0 Hz	2 GHz	General Purpose	36 dB	32 dBm	Reflective	0.9 dB	Surface Mount	1.65 V	2.75 V	SPDT	2		16 dBm	-40 °C	85 °C	1 GHz
Analog Devices Inc./Maxim Integrated ADG936BRUZ							50 Ohm	0.173 in	20-TSSOP	4.4 mm	0 Hz	2 GHz	General Purpose	36 dB	32 dBm	Absorptive	0.9 dB	Surface Mount	1.65 V	2.75 V	SPDT	2		16 dBm	-40 °C	85 °C	1 GHz
Analog Devices Inc./Maxim Integrated ADG936BRUZ-R							50 Ohm	0.173 in	20-TSSOP	4.4 mm	0 Hz	2 GHz	General Purpose	36 dB	32 dBm	Reflective	0.9 dB	Surface Mount	1.65 V	2.75 V	SPDT	2		16 dBm	-40 °C	85 °C	1 GHz
Analog Devices Inc./Maxim Integrated ADG936BRU							50 Ohm	0.173 in	20-TSSOP	4.4 mm	0 Hz	2 GHz	General Purpose	36 dB	32 dBm	Absorptive	0.9 dB	Surface Mount	1.65 V	2.75 V	SPDT	2		16 dBm	-40 °C	85 °C	1 GHz
Analog Devices Inc./Maxim Integrated EVAL-ADG936REBZ			ADG936	1 GHz	Board	SPDT Switch
Analog Devices Inc./Maxim Integrated ADG936BRU-R-REEL							50 Ohm	0.173 in	20-TSSOP	4.4 mm	0 Hz	2 GHz	General Purpose	36 dB	32 dBm	Reflective	0.9 dB	Surface Mount	1.65 V	2.75 V	SPDT	2		16 dBm	-40 °C	85 °C	1 GHz
Analog Devices Inc./Maxim Integrated ADG936BCPZ-RL7							50 Ohm	4 mm	20-LFCSP	4 mm	0 Hz	2 GHz	ASK FSK	60 dB	36 dBm	Reflective	0.4 dB	Surface Mount	1.65 V	2.75 V			20-WFQFN Exposed Pad CSP	17 dBm	-40 °C	85 °C	100 MHz	SPDT
Analog Devices Inc./Maxim Integrated ADG936BCPZ-RL							50 Ohm	4 mm	20-LFCSP	4 mm	0 Hz	2 GHz	General Purpose	36 dB	32 dBm	Absorptive	0.9 dB	Surface Mount	1.65 V	2.75 V	SPDT	2	20-WFQFN Exposed Pad CSP	16 dBm	-40 °C	85 °C	1 GHz		Single Line Control
