AD827 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

HIGH SPEED, LOW POWER DUAL OP AMP

Part	Voltage - Supply Span (Min)	Slew Rate	Current - Supply	Gain Bandwidth Product	Voltage - Input Offset	Number of Circuits	Amplifier Type	Package Length	Package Name	Package Width	Mounting Type	Current - Input Bias	Voltage - Supply Span (Max)	Operating Temperature (Max)	Operating Temperature (Min)	Current - Output / Channel	Package / Case
Analog Devices Inc./Maxim Integrated AD827JNZ	9 V	300 V/µs	10 mA	50 MHz	300 µV	2	General Purpose	0.3 in	8-DIP 8-PDIP	7.62 mm	Through Hole	3.3 µA	36 V	70 °C	0 °C	32 mA
Analog Devices Inc./Maxim Integrated AD827JN	9 V	300 V/µs	10 mA	50 MHz	300 µV	2	General Purpose	0.3 in	8-DIP 8-PDIP	7.62 mm	Through Hole	3.3 µA	36 V	70 °C	0 °C	32 mA
Analog Devices Inc./Maxim Integrated AD827JRZ-16-REEL7	9 V	300 V/µs	10 mA	50 MHz	300 µV	2	General Purpose	0.295 in	16-SOIC	7.5 mm	Surface Mount	3.3 µA	36 V	70 °C	0 °C	32 mA
Analog Devices Inc./Maxim Integrated AD827JR-16-REEL7	9 V	300 V/µs	10 mA	50 MHz	300 µV	2	General Purpose	0.295 in	16-SOIC	7.5 mm	Surface Mount	3.3 µA	36 V	70 °C	0 °C	32 mA
Analog Devices Inc./Maxim Integrated AD827JR-16	9 V	300 V/µs	10 mA	50 MHz	300 µV	2	General Purpose	0.295 in	16-SOIC	7.5 mm	Surface Mount	3.3 µA	36 V	70 °C	0 °C	32 mA
Analog Devices Inc./Maxim Integrated 5962-9211701MPA	9 V	300 V/µs	10 mA	50 MHz	300 µV	2	General Purpose	0.3 in	8-CDIP 8-CERDIP	7.62 mm	Through Hole	3.3 µA	36 V	125 °C	-55 °C	32 mA
Analog Devices Inc./Maxim Integrated 5962-9211701M2A	9 V	300 V/µs	10 mA	50 MHz	300 µV	2	General Purpose	9 mm	20-CLCC	9 mm	Surface Mount	3.3 µA	36 V	125 °C	-55 °C	32 mA	20-CLCC
Analog Devices Inc./Maxim Integrated AD827SE/883B	9 V	300 V/µs	10 mA	50 MHz	300 µV	2	General Purpose	9 mm	20-CLCC	9 mm	Surface Mount	3.3 µA	36 V	125 °C	-55 °C	32 mA	20-CLCC
Analog Devices Inc./Maxim Integrated AD827SQ	9 V	300 V/µs	10 mA	50 MHz	300 µV	2	General Purpose	0.3 in	8-CDIP 8-CERDIP	7.62 mm	Through Hole	3.3 µA	36 V	125 °C	-55 °C	32 mA
