D38999/26KD Series
Manufacturer: Amphenol Aerospace Operations
Beta
⌘K
D38999/26KD15AB
| Part | Number of Positions | Shell Material | Housing Color | Ingress Protection Description | Ingress Protection IP Rating | Note | Contact Type | Features | Shielding | Operating Temperature (Max) | Operating Temperature (Min) | Fastening Type | Shell Finish | Contact Size | Mounting Type | Contact Shape | Type | Shell Size - Insert (Maximum) | Shell Size - Insert (Minimum) | Connector Type | Shell Size (MIL) | Orientation | Insert Material | Termination | Applications | Contact Finish - Mating | Contact Material | Ingress Protection | Qualification | Color | Grade | Primary Material | Contact Finish Thickness - Mating | Contact Size Options | Current Rating Options |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol Aerospace Operations | 15 | Stainless Steel | Silver | Dust Tight Waterproof | IP67 | Contacts Not Included | Crimp | Coupling Nut Firewall Usage | Shielded | 200 °C | -65 °C | Threaded | Passivated | 16 20 | Free Hanging (In-Line) | Circular | For Male Pins | 15 | 15 | Plug Housing | D | B | Thermoplastic | ||||||||||||
Amphenol Aerospace Operations | 12 | Shielded | Threaded | Free Hanging (In-Line) | 97 | 15 | Male Pins Plug | D | B | Crimp | Aviation Marine Military | Gold | |||||||||||||||||||||||
 Amphenol Aerospace Operations | 37 pos | Stainless Steel | Coupling Nut Firewall Usage | Shielded | 200 °C | -65 °C | Threaded | Free Hanging (In-Line) | 35 | 15 | Male Pins Plug | D | N (Normal) | Thermoplastic | Crimp | Aerospace Aviation Marine Military | Gold | Copper Alloy | Environment Resistant | MIL-DTL-38999 Series III | Silver | Military | Metal | 50 µin | |||||||||||
Amphenol Aerospace Operations | 5 | Crimp | Threaded | Free Hanging (In-Line) | For Male Pins | Plug Housing | D | B | Metal | ||||||||||||||||||||||||||
Amphenol Aerospace Operations | |||||||||||||||||||||||||||||||||||
Amphenol Aerospace Operations | 37 pos | Stainless Steel | Silver | Dust Tight Waterproof | IP67 | Contacts Not Included | Crimp | Coupling Nut Firewall Usage | Shielded | 200 °C | -65 °C | Threaded | Passivated | Free Hanging (In-Line) | Circular | For Male Pins | 35 | 15 | Plug Housing | D | C | Thermoplastic | 22D | ||||||||||||
Amphenol Aerospace Operations | |||||||||||||||||||||||||||||||||||
Amphenol Aerospace Operations | |||||||||||||||||||||||||||||||||||
Amphenol Aerospace Operations | 15 | Stainless Steel | Dust Tight Waterproof | IP67 | Coupling Nut | Shielded | 200 °C | -65 °C | Threaded | Passivated | Free Hanging (In-Line) | 15 | 15 | Female Sockets Plug | D | B | Thermoplastic | Crimp | Aviation Marine Military | Gold | Copper Alloy | Metal | 50 µin | 13A 7.5A | |||||||||||
Amphenol Aerospace Operations | 18 | Stainless Steel | Silver | Dust Tight Waterproof | IP67 | Contacts Not Included | Crimp | Coupling Nut Firewall Usage | Shielded | 200 °C | -65 °C | Threaded | Passivated | 20 | Free Hanging (In-Line) | Circular | For Male Pins | 18 | 15 | Plug Housing | D | B | Thermoplastic |
