AD8607 Series

Catalog

OPERATIONAL AMPLIFIER, 2 CHANNELS, 400 KHZ, 0.1 V/ΜS, 1.8V TO 5V, NSOIC, 8 PINS

Part	Current - Output / Channel	Amplifier Type	Number of Circuits	Current - Input Bias	Voltage - Supply Span (Min)	Operating Temperature (Max)	Operating Temperature (Min)	Slew Rate	Mounting Type	Voltage - Input Offset	Package Length	Package Name	Package Width	Output Type	Voltage - Supply Span (Max)	Gain Bandwidth Product	Current - Supply
Analog Devices Inc./Maxim Integrated AD8607ARZ	70 mA	CMOS	2	0.2 pA	1.8 V	125 °C	-40 °C	0.1 V/µs	Surface Mount	12 µV	0.154 in	8-SOIC	3.9 mm	Rail-to-Rail	5 V	400 kHz	40 µA
Analog Devices Inc./Maxim Integrated AD8607ARM-R2	70 mA	CMOS	2	0.2 pA	1.8 V	125 °C	-40 °C	0.1 V/µs	Surface Mount	12 µV	0.118 in	8-MSOP 8-TSSOP 8-MSOP	3 mm	Rail-to-Rail	5 V	400 kHz	40 µA
Analog Devices Inc./Maxim Integrated AD8607ARZ-REEL7	70 mA	CMOS	2	0.2 pA	1.8 V	125 °C	-40 °C	0.1 V/µs	Surface Mount	12 µV	0.154 in	8-SOIC	3.9 mm	Rail-to-Rail	5 V	400 kHz	40 µA
