AD8422 Series
Manufacturer: Analog Devices Inc./Maxim Integrated
Beta
⌘K
INSTRUMENT AMPLIFIER, 1 CHANNELS, 60 ΜV, 0.8 V/ΜS, 2.2 MHZ, ± 2.3V TO ± 18V, 4.6V TO 36V, NSOIC
| Part | Operating Temperature (Min) | Operating Temperature (Max) | Voltage - Input Offset | Current - Supply | Current - Input Bias | Package Length | Package Name | Package Width | Current - Output / Channel | Mounting Type | -3db Bandwidth | Amplifier Type | Voltage - Supply Span (Min) | Voltage - Supply Span (Max) | Output Type | Number of Circuits | Slew Rate | Contents | Current - Supply (Main IC) | Channels per IC (Single) | Channels per IC (Type) | Channels per IC (Count) | Utilized IC / Part | Supply Configuration | Voltage - Supply (Single) Minimum | Voltage - Supply (Single) Maximum | Voltage - Supply (Dual) Maximum (Magnitude) | Voltage - Supply (Dual) Minimum (Magnitude) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Analog Devices Inc./Maxim Integrated | -40 °C | 85 °C | 60 µV | 300 µA | 500 pA | 0.154 in | 8-SOIC | 3.9 mm | 20 mA | Surface Mount | 2.2 MHz | Instrumentation | 4.6 V | 36 V | Rail-to-Rail | 1 | 0.8 V/µs | |||||||||||
 Analog Devices Inc./Maxim Integrated | -40 °C | 85 °C | 70 µV | 300 µA | 500 pA | 0.118 in | 8-MSOP 8-TSSOP 8-MSOP | 3 mm | 20 mA | Surface Mount | 2.2 MHz | Instrumentation | 4.6 V | 36 V | Rail-to-Rail | 1 | 0.8 V/µs | |||||||||||
 Analog Devices Inc./Maxim Integrated | 20 mA | 2.2 MHz | Instrumentation | Rail-to-Rail Single-Ended | 0.8 V/µs | Board | 0.000338 µA | 1 | Single | 1 | AD8422 | Dual Single | 4.6 V | 36 V | 18 V | 2.3 V | ||||||||||||
Analog Devices Inc./Maxim Integrated | -40 °C | 85 °C | 50 µV | 300 µA | 200 pA | 0.118 in | 8-MSOP 8-TSSOP 8-MSOP | 3 mm | 20 mA | Surface Mount | 2.2 MHz | Instrumentation | 4.6 V | 36 V | Rail-to-Rail | 1 | 0.8 V/µs | |||||||||||
Analog Devices Inc./Maxim Integrated | -40 °C | 85 °C | 60 µV | 300 µA | 500 pA | 0.154 in | 8-SOIC | 3.9 mm | 20 mA | Surface Mount | 2.2 MHz | Instrumentation | 4.6 V | 36 V | Rail-to-Rail | 1 | 0.8 V/µs | |||||||||||
Analog Devices Inc./Maxim Integrated | -40 °C | 85 °C | 50 µV | 300 µA | 200 pA | 0.118 in | 8-MSOP 8-TSSOP 8-MSOP | 3 mm | 20 mA | Surface Mount | 2.2 MHz | Instrumentation | 4.6 V | 36 V | Rail-to-Rail | 1 | 0.8 V/µs | |||||||||||
Analog Devices Inc./Maxim Integrated | -40 °C | 85 °C | 50 µV | 300 µA | 200 pA | 0.118 in | 8-MSOP 8-TSSOP 8-MSOP | 3 mm | 20 mA | Surface Mount | 2.2 MHz | Instrumentation | 4.6 V | 36 V | Rail-to-Rail | 1 | 0.8 V/µs |
