BB-02BFMA Series

Catalog

X-LOK, STANDARD SIZE, PLASTIC, 10A, 02 PINS, FEMALE CONNECTOR, MALE CONTACT, STRAIGHT, PUSH LOCK, CRIMP, FIELD INSTALLABLE, 8.0

Part	Insert Material	Primary Material	Contact Finish - Mating	Shell Material	Mounting Type	Operating Temperature (Min)	Operating Temperature (Max)	Shielding	Ingress Protection IP Rating	Ingress Protection Description	Color	Voltage Rating	Voltage Rating (Type)	Cable Opening (Max)	Cable Opening (Min)	Connector Type	Termination	Material Flammability Rating	Contact Material	Orientation	Fastening Type	Features	Number of Positions	Position Types	Shell Size - Insert	Current Rating	Housing Color	Shell Size (MIL)	Type	Contact Type	Contact Shape	Note	Shell Finish	Backshell Material, Plating
McGill Microwave Systems BB-02BFMA-QL8LPP	Glass Filled Nylon PA Polyamide	Plastic	Gold	Glass Filled Nylon Polyamide (PA)	Free Hanging (In-Line)	-40 °C	105 °C	Unshielded	IP68	Dust Tight Waterproof	Black	300 VAC/DC	DC	0.394 in	0.315 in	Male Pins Plug	Crimp	UL94 V-0	Copper Alloy	Keyed	Push-Pull	Backshell	2	Power	B	10 A
McGill Microwave Systems BB-02BFMA-QL8SPP	Glass Filled Nylon PA Polyamide	Plastic	Gold	Glass Filled Nylon Polyamide (PA)	Free Hanging (In-Line)	-40 °C	105 °C	Unshielded	IP68	Dust Tight Waterproof	Black	300 VAC/DC	DC	0.236 in	0.197 in	Male Pins Plug	Crimp	UL94 V-0	Copper Alloy	Keyed	Push-Pull	Backshell	2	Power	B	10 A
McGill Microwave Systems BB-02BFMA-QL8ANP	Thermoplastic	Plastic		Thermoplastic	Free Hanging (In-Line)	-40 °C	105 °C	Unshielded	IP68	Dust Tight Waterproof						Plug Housing				Keyed	Push-Pull	Backshell	2		B		Black	B	For Male Pins	Crimp	Circular	Contacts Not Included
McGill Microwave Systems BB-02BFMA-QL8MPP	Glass Filled Nylon PA Polyamide	Plastic	Gold	Glass Filled Nylon Polyamide (PA)	Free Hanging (In-Line)	-20 °C	105 °C	Unshielded	IP68	Dust Tight Waterproof	Black					Male Pins Plug	Crimp	UL94 V-0	Copper Alloy	Keyed	Push-Pull	Backshell Strain Relief	2	Power	B	10 A
McGill Microwave Systems BB-02BFMA-SL7001	Glass Filled Nylon PA Polyamide	Plastic	Gold		Free Hanging (In-Line)	-40 °C	105 °C	Unshielded	IP67	Dust Tight Waterproof	Black	250 V	DC	0.256 in	0.177 in	Male Pins Plug	Solder Cup	UL94 V-0	Copper Alloy	Keyed	Threaded	Backshell Coupling Nut	2		B	10 A							Nickel	Nylon Polyamide (PA)
McGill Microwave Systems BB-02BFMA-QL8APP	Glass Filled Nylon PA Polyamide	Plastic	Gold	Glass Filled Nylon Polyamide (PA)	Free Hanging (In-Line)	-40 °C	105 °C	Unshielded	IP68	Dust Tight Waterproof	Black	300 VAC/DC	DC			Male Pins Plug	Crimp	UL94 V-0	Copper Alloy	Keyed	Push-Pull	Backshell Strain Relief	2	Power	B	10 A
McGill Microwave Systems BB-02BFMA-QL8SNP	Thermoplastic	Plastic		Thermoplastic	Free Hanging (In-Line)	-40 °C	105 °C	Unshielded	IP68	Dust Tight Waterproof						Plug Housing				Keyed	Push-Pull	Backshell	2		B		Black	B	For Male Pins	Crimp	Circular	Contacts Not Included
McGill Microwave Systems BB-02BFMA-LL7001	Glass Filled Nylon PA Polyamide	Plastic	Gold		Free Hanging (In-Line)	-40 °C	105 °C	Unshielded	IP67	Dust Tight Waterproof	Black	250 V	DC	0.256 in	0.177 in	Male Pins Plug	Solder Cup	UL94 V-0	Copper Alloy	Keyed	Bayonet Lock	Backshell Coupling Nut	2		B	10 A							Nickel	Nylon Polyamide (PA)
McGill Microwave Systems BB-02BFMA-LL6001	Glass Filled Nylon PA Polyamide	Plastic	Gold		Free Hanging (In-Line)	-40 °C	105 °C	Unshielded	IP66	Dust Tight Water Resistant	Black	250 V	DC			Male Pins Plug	Solder Cup	UL94 V-0	Copper Alloy	Keyed	Bayonet Lock	Backshell Coupling Nut	2		B	10 A							Nickel	Nylon Polyamide (PA)
