ADM2485 Series
Manufacturer: Analog Devices Inc./Maxim Integrated
Beta
⌘K
2.5 KV SIGNAL ISOLATED, HIGH SPEED (16 MBPS), HALF DUPLEX RS-485 TRANSCEIVER W/ TRANSFORMER DRIVER
| Part | Mounting Type | Inputs - Side 1 | Inputs - Side 2 | Package Name | Voltage - Isolation | Type | Propagation Delay tpHL (Max) | Propagation Delay tpLH (Max) | Isolated Power | Operating Temperature (Min) | Operating Temperature (Max) | Channel Type | Package Length | Package Width | Data Rate | Number of Channels | Technology | Voltage - Supply | Voltage - Supply | Rise Time (Typ) | Fall Time (Typ) | Common Mode Transient Immunity (Min) | Utilized IC / Part | Function | Contents |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Analog Devices Inc./Maxim Integrated | Surface Mount | 2 | 1 | 16-SOIC | 2500 Vrms | RS422 RS485 | 55 ns | 55 ns | No | -40 °C | 85 °C | Bidirectional | 0.295 in | 7.5 mm | 16 MBd | 3 | Magnetic Coupling | 3.3 V 5 VDC | 3.3V 5V | 5 ns | 5 ns | 25 kV/µs | |||
 Analog Devices Inc./Maxim Integrated | Interface | ADM2485 | RS-422 RS-485 Transceiver | Board | |||||||||||||||||||||
Analog Devices Inc./Maxim Integrated | Surface Mount | 2 | 1 | 16-SOIC | 2500 Vrms | RS422 RS485 | 55 ns | 55 ns | No | -40 °C | 85 °C | Bidirectional | 0.295 in | 7.5 mm | 16 MBd | 3 | Magnetic Coupling | 3.3 V 5 VDC | 3.3V 5V | 5 ns | 5 ns | 25 kV/µs |
