NMB2-12 Series
Manufacturer: Pepperl+Fuchs, Inc.
Beta
⌘K
INDUCTIVE SEN 2MM NO XYLAN COAT
| Part | Sensing Distance | Shielding | Indicator | Termination Style | Operating Temperature (Max) | Operating Temperature (Min) | Ingress Protection | Sensor Type | Output Type | Voltage - Supply (Maximum) | Voltage - Supply (Minimum) | Material - Body | Package / Case | Voltage - Supply (Range 2 Maximum) | Voltage - Supply (Range 1 Minimum) | Voltage - Supply (Range 1 Maximum) | Voltage - Supply (Range 2 Minimum) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Pepperl+Fuchs, Inc. | 0.079 " | Unshielded | LED | Cable with Connector | 70 °C | -25 °C | IP67 IP68 IP69K | Inductive | 2-Wire SCR-NO | 30 VDC | 6 V | Stainless Steel | Cylinder Threaded - M12 | ||||
 Pepperl+Fuchs, Inc. | 0.079 " | Unshielded | LED | Connector | 70 °C | -25 °C | IP67 IP68 IP69K | Inductive | 3-Wire PNP-NO | 30 VDC | 10 VDC | Stainless Steel | Cylinder Threaded - M12 | ||||
 Pepperl+Fuchs, Inc. | 0.079 " | Unshielded | LED | Connector | 70 °C | -40 °C | IP67 IP68 IP69K | Inductive | 3-Wire PNP-NO | 30 VDC | 10 VDC | Stainless Steel | Cylinder Threaded - M12 | ||||
 Pepperl+Fuchs, Inc. | 0.079 " | Unshielded | LED | Connector | 70 °C | -25 °C | IP67 IP68 IP69K | Inductive | 2-Wire SCR-NO | Stainless Steel | Cylinder Threaded - M12 | 300 VDC | 20 VAC | 250 VAC | 20 VDC |
