V709 Series

Catalog

CONNECTOR: PLUGGABLE TERMINAL BLOCK; SOCKET; FEMALE; 8A; 300V

Part	Operating Temperature (Min)	Operating Temperature (Max)	Color	Number of Levels	Number of Positions	Termination Style	Features	Header Orientation Angle	Header Orientation	Contact Mating Finish	Type	Positions Per Level	Current - UL	Voltage - UL	Mounting Type	Pitch	Insulation Height	Housing Material	Contact Material	Material Flammability Rating	Contact Tail Length
McGill Microwave Systems V70932510000G	-40 °C	115 °C	Green	1	9	Solder	Mating Flange	90 °	Right Angle	Tin	Female Sockets Header	9	8 A	300 V	Through Hole	0.15 in	0.268 in	Thermoplastic	Phosphor Bronze	UL94 V-0	0.134 in
McGill Microwave Systems V70972500000G	-40 °C	115 °C	Green	1	9	Solder	Mating Flange Retention Latches		Vertical	Tin	Female Sockets Header	9	10 A	300 V	Through Hole	0.197 in	0.748 in	Thermoplastic	Phosphor Bronze	UL94 V-0	0.138 in
McGill Microwave Systems V709A2510000G	-40 °C	115 °C	Green	1	9	Solder	Mating Flange Retention Latches	90 °	Right Angle	Tin	Female Sockets Header	9	10 A	300 V	Through Hole	0.295 in		Thermoplastic	Phosphor Bronze	UL94 V-0	0.138 in
McGill Microwave Systems V70912510000G	-40 °C	115 °C	Green	1	9	Solder	Mating Flange	90 °	Right Angle	Tin	Female Sockets Header	9	4 A	300 V	Through Hole	0.138 in	0.268 in	Thermoplastic	Phosphor Bronze	UL94 V-0	0.134 in
McGill Microwave Systems V70912500000G	-40 °C	115 °C	Green	1	9	Solder	Mating Flange		Vertical	Tin	Female Sockets Header	9	4 A	300 V	Through Hole	0.138 in	0.571 in	Thermoplastic	Phosphor Bronze	UL94 V-0	0.134 in
McGill Microwave Systems V70972510000G	-40 °C	115 °C	Green	1	9	Solder	Mating Flange Retention Latches	90 °	Right Angle	Tin	Female Sockets Header	9	10 A	300 V	Through Hole	0.197 in	0.425 in	Thermoplastic	Phosphor Bronze	UL94 V-0	0.138 in
McGill Microwave Systems V709A1510000G	-40 °C	115 °C	Green	1	9	Solder	Retention Latches	90 °	Right Angle	Tin	Female Sockets Header	9	10 A	300 V	Through Hole	0.295 in		Thermoplastic	Phosphor Bronze	UL94 V-0	0.138 in
McGill Microwave Systems V70911500000G	-40 °C	115 °C	Green	1	9	Solder			Vertical	Tin	Female Sockets Header	9	4 A	300 V	Through Hole	0.138 in	0.571 in	Thermoplastic	Phosphor Bronze	UL94 V-0	0.134 in
McGill Microwave Systems V70931510000G	-40 °C	115 °C	Green	1	9	Solder		90 °	Right Angle	Tin	Female Sockets Header	9	8 A	300 V	Through Hole	0.15 in	0.26 in	Thermoplastic	Phosphor Bronze	UL94 V-0	0.134 in
McGill Microwave Systems V70951510000G	-40 °C	115 °C	Green	1	9	Solder	Retention Latches	90 °	Right Angle	Tin	Female Sockets Header	9	20 A	300 V	Through Hole	5.08 mm		Thermoplastic	Copper	UL94 V-0	0.138 in
