ADF4193 Series

Catalog

LOW PHASE NOISE, FAST SETTLING PLL FREQUENCY SYNTHESIZER

Part	Number of Circuits	Mounting Type	Package Width	Package Name	Package Length	Type	Input	Divider	Multiplier	Package / Case	Operating Temperature (Min)	Operating Temperature (Max)	PLL	Input Ratio	Output Ratio	Output	Differential Input	Differential Output	Frequency - Max	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Grade
Analog Devices Inc./Maxim Integrated ADF4193BCPZ-RL	1	Surface Mount	5 mm	32-LFCSP-WQ	5 mm	Clock/Frequency Synthesizer (RF)	CMOS TTL	Yes	Yes	32-WFQFN Exposed Pad CSP	-40 °C	85 °C	Yes	2	1	Clock	Yes	No	3.5 GHz	3.3 V	2.7 V
Analog Devices Inc./Maxim Integrated ADF4193BCPZ-RL7	1	Surface Mount	5 mm	32-LFCSP-WQ	5 mm	Clock/Frequency Synthesizer (RF)	CMOS TTL	Yes	Yes	32-WFQFN Exposed Pad CSP	-40 °C	85 °C	Yes	2	1	Clock	Yes	No	3.5 GHz	3.3 V	2.7 V
Analog Devices Inc./Maxim Integrated ADF4193WCCPZ-RL7	1	Surface Mount	5 mm	32-LFCSP-WQ	5 mm	Clock/Frequency Synthesizer (RF)	CMOS TTL	Yes	Yes	32-WFQFN Exposed Pad CSP	-40 °C	105 °C	Yes	2	1	Clock	Yes	No	3.5 GHz	3.3 V	2.7 V	Automotive
Analog Devices Inc./Maxim Integrated ADF4193BCPZ	1	Surface Mount	5 mm	32-LFCSP-WQ	5 mm	Clock/Frequency Synthesizer (RF)	CMOS TTL	Yes	Yes	32-WFQFN Exposed Pad CSP	-40 °C	85 °C	Yes	2	1	Clock	Yes	No	3.5 GHz	3.3 V	2.7 V
