97-3102A18 Series
Manufacturer: Amphenol Aerospace Operations
Beta
⌘K
CONN RCPT FMALE 10P SOLDER CUP
| Part | Mounting Type | Shell Size - Insert Length | Shell Size - Insert Width | Shielding | Contact Finish - Mating | Termination | Shell Material | Primary Material | Number of Positions | Insert Material | Orientation | Operating Temperature (Max) | Operating Temperature (Min) | Shell Finish | Applications | Fastening Type | Color | Mounting Feature | Contact Material | Connector Type | Shell Size - Insert (Minimum) | Shell Size - Insert (Maximum) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol Aerospace Operations | Panel Mount | 18 mm | 1 mm | Unshielded | Silver | Solder Cup | Aluminum Alloy | Metal | 10 | DAP Diallyl Phthalate | N (Normal) | 125 °C | -55 °C | Black Zinc Alloy | Automotive Industrial | Threaded | Black | Flange | Copper Alloy | Female Sockets Receptacle | ||
 Amphenol Aerospace Operations | Panel Mount | 18 mm | 12 mm | Unshielded | Silver | Solder Cup | Aluminum Alloy | Metal | 6 | DAP Diallyl Phthalate | N (Normal) | 125 °C | -55 °C | Cadmium Olive Drab Chromate | Automotive Industrial | Threaded | Olive Drab | Flange | Copper Alloy | Male Pins Receptacle | ||
 Amphenol Aerospace Operations | Panel Mount | 18 mm | 12 mm | Unshielded | Silver | Solder Cup | Aluminum Alloy | Metal | 6 | DAP Diallyl Phthalate | N (Normal) | 125 °C | -55 °C | Black Zinc Alloy | Automotive Industrial | Threaded | Black | Flange | Copper Alloy | Female Sockets Receptacle | ||
Amphenol Aerospace Operations | Panel Mount | 18 mm | 12 mm | Unshielded | Silver | Solder Cup | Aluminum Alloy | Metal | 6 | DAP Diallyl Phthalate | N (Normal) | 125 °C | -55 °C | Black Zinc Alloy | Automotive Industrial | Threaded | Black | Flange | Copper Alloy | Male Pins Receptacle | ||
 Amphenol Aerospace Operations | Panel Mount | 18 mm | 1 mm | Unshielded | Silver | Solder Cup | Aluminum Alloy | Metal | 10 | DAP Diallyl Phthalate | N (Normal) | 125 °C | -55 °C | Cadmium Olive Drab Chromate | Automotive Industrial | Threaded | Olive Drab | Flange | Copper Alloy | Male Pins Receptacle | ||
 Amphenol Aerospace Operations | Panel Mount | 18 mm | 4 mm | Unshielded | Silver | Solder Cup | Aluminum Alloy | Metal | 4 | DAP Diallyl Phthalate | N (Normal) | 125 °C | -55 °C | Black Zinc Alloy | Automotive Industrial | Threaded | Black | Flange | Copper Alloy | Male Pins Receptacle | ||
 Amphenol Aerospace Operations | Panel Mount | 18 mm | 11 mm | Unshielded | Silver | Solder Cup | Aluminum Alloy | Metal | 5 | DAP Diallyl Phthalate | N (Normal) | 125 °C | -55 °C | Cadmium Olive Drab Chromate | Automotive Industrial | Threaded | Olive Drab | Flange | Copper Alloy | Female Sockets Receptacle | ||
 Amphenol Aerospace Operations | Panel Mount | Unshielded | Silver | Solder Cup | Aluminum Alloy | Metal | 10 | DAP Diallyl Phthalate | N (Normal) | 125 °C | -55 °C | Black Zinc Alloy | Automotive Industrial | Threaded | Black | Flange | Copper Alloy | Female Sockets Receptacle | 18 | 19 | ||
 Amphenol Aerospace Operations | Panel Mount | 18 mm | 8 mm | Unshielded | Silver | Solder Cup | Aluminum Alloy | Metal | 8 | DAP Diallyl Phthalate | N (Normal) | 125 °C | -55 °C | Black Zinc Alloy | Automotive Industrial | Threaded | Black | Flange | Copper Alloy | Female Sockets Receptacle | ||
 Amphenol Aerospace Operations | Panel Mount | 18 mm | 10 mm | Unshielded | Silver | Solder Cup | Aluminum Alloy | Metal | 4 | DAP Diallyl Phthalate | N (Normal) | 125 °C | -55 °C | Cadmium Olive Drab Chromate | Automotive Industrial | Threaded | Olive Drab | Flange | Copper Alloy | Male Pins Receptacle |
