AD8054 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

LOW COST, HIGH SPEED, RAIL-TO-RAIL AMPLIFIER

Part	Slew Rate	-3db Bandwidth	Current - Supply	Number of Circuits	Amplifier Type	Current - Output / Channel	Voltage - Input Offset	Voltage - Supply Span (Max)	Mounting Type	Operating Temperature (Max)	Operating Temperature (Min)	Package Width	Package Name	Package Length	Output Type	Voltage - Supply Span (Min)	Current - Input Bias	Board Type	Supplied Contents	Contents	Channels per IC (Quad)	Channels per IC (Type)	Channels per IC (Count)	Utilized IC / Part
Analog Devices Inc./Maxim Integrated AD8054ARUZ	190 V/µs	160 MHz	2.875 mA	4	Voltage Feedback	30 mA	1.8 mV	12 V	Surface Mount	125 °C	-40 °C	4.4 mm	14-TSSOP	0.173 in	Rail-to-Rail	3 V	2 µA
Analog Devices Inc./Maxim Integrated AD8054AR-REEL7	190 V/µs	160 MHz	2.875 mA	4	Voltage Feedback	30 mA	1.8 mV	12 V	Surface Mount	125 °C	-40 °C	3.9 mm	14-SOIC	0.154 in	Rail-to-Rail	3 V	2 µA
Analog Devices Inc./Maxim Integrated AD8054ARU-REEL7	190 V/µs	160 MHz	2.875 mA	4	Voltage Feedback	30 mA	1.8 mV	12 V	Surface Mount	125 °C	-40 °C	4.4 mm	14-TSSOP	0.173 in	Rail-to-Rail	3 V	2 µA
Analog Devices Inc./Maxim Integrated AD8054ARU-REEL	190 V/µs	160 MHz	2.875 mA	4	Voltage Feedback	30 mA	1.8 mV	12 V	Surface Mount	125 °C	-40 °C	4.4 mm	14-TSSOP	0.173 in	Rail-to-Rail	3 V	2 µA
Analog Devices Inc./Maxim Integrated AD8054ARZ-REEL7	190 V/µs	160 MHz	2.875 mA	4	Voltage Feedback	30 mA	1.8 mV	12 V	Surface Mount	125 °C	-40 °C	3.9 mm	14-SOIC	0.154 in	Rail-to-Rail	3 V	2 µA
Analog Devices Inc./Maxim Integrated AD8054ARU-EBZ					Voltage Feedback													Bare (Unpopulated)	Board(s)	Unpopulated (Bare) Board	4	Quad	4	14-TSSOP Package
Analog Devices Inc./Maxim Integrated AD8054ARUZ-REEL7	190 V/µs	160 MHz	2.875 mA	4	Voltage Feedback	30 mA	1.8 mV	12 V	Surface Mount	125 °C	-40 °C	4.4 mm	14-TSSOP	0.173 in	Rail-to-Rail	3 V	2 µA
