ACJC6 Series

Catalog

1/4" STEREO/XLR PCB 6 SKT

Part	Panel Hole Size	Body Color	Contact Material	Contact Material - Plating	Housing Material	Current Rating	Mounting Type	Number of Contacts	Number of Conductors	Termination	Gender	Features	Internal Switch(s)	Shielding	Connector Type	Operating Temperature (Max)	Operating Temperature (Min)	Industry Recognized Mating Diameter (Headphone)	Signal Lines
McGill Microwave Systems ACJC6H BULK	0.937 in	Black	Brass Bronze	Gold Silver	Glass Filled Nylon 6/6 PA66 Polyamide	7.5 A	Panel Mount Right Angle Through Hole	7 Contacts	3 Conductors	Kinked Pin Solder	Female	Board Guide	Does Not Contain Switch	Unshielded	Dual Phone Jack	70 °C	-25 °C	6.35 mm	3 Conductor Stereo TRS
McGill Microwave Systems ACJC6AH BULK	0.937 in	Black	Brass Bronze	Gold Silver	Glass Filled Nylon 6/6 PA66 Polyamide	7.5 A	Panel Mount Right Angle Through Hole	7 Contacts	3 Conductors	Kinked Pin Solder	Female	Board Guide	Does Not Contain Switch	Unshielded	Dual Phone Jack	70 °C	-25 °C	6.35 mm	3 Conductor Stereo TRS
McGill Microwave Systems ACJC6V BULK	0.937 in	Black	Brass Bronze	Gold Silver	Glass Filled Nylon 6/6 PA66 Polyamide	7.5 A	Panel Mount Through Hole	7 Contacts	3 Conductors	Kinked Pin Solder	Female	Board Guide	Does Not Contain Switch	Unshielded	Dual Phone Jack	70 °C	-25 °C	6.35 mm	3 Conductor Stereo TRS
