GF-CGRADE-MINI Series

Catalog

BOARD MOUNT PRESSURE SENSORS GAUGE MILLIVOLT CPC

Part	Operating Pressure	Accuracy	Features	Package / Case	Port Style	Termination Style	Applications	Port Diameter	Port Feature	Port Gender	Maximum Pressure	Voltage - Supply	Output Voltage (Min)	Output Voltage (Max)	Output Type	Operating Temperature (Max)	Operating Temperature (Min)	Mounting Type	Pressure Type
McGill Microwave Systems 10 INCH-GF-CGRADE-MINI	0.36 PSI	1 %	Temperature Compensated	4-SIP Module	Barbless	PC Pin	Board Mount	0.18 in	Tube	Male	20 PSI	16 V	0 mV	20 mV	Wheatstone Bridge	85 °C	-25 °C	Through Hole	Vented Gauge
McGill Microwave Systems 5 PSI-GF-CGRADE-MINI	5 PSI	1 %	Temperature Compensated	4-SIP Module	Barbless	PC Pin	Board Mount	0.18 in	Tube	Male	20 PSI	16 V	0 mV	60 mV	Wheatstone Bridge	85 °C	-25 °C	Through Hole	Vented Gauge
McGill Microwave Systems 0.3 PSI-GF-CGRADE-MINI	0.3 PSI	1 %	Temperature Compensated	4-SIP Module	Barbless	PC Pin	Board Mount	0.18 in	Tube	Male	3 PSI	16 V	0 mV	20 mV	Wheatstone Bridge	85 °C	-25 °C	Through Hole	Vented Gauge
McGill Microwave Systems 15 PSI-GF-CGRADE-MINI	15 PSI	1 %	Temperature Compensated	4-SIP Module	Barbless	PC Pin	Board Mount	0.18 in	Tube	Male	60 PSI	16 V	0 mV	90 mV	Wheatstone Bridge	85 °C	-25 °C	Through Hole	Vented Gauge
McGill Microwave Systems 4 INCH-GF-CGRADE-MINI	0.15 PSI	1 %	Temperature Compensated	4-SIP Module	Barbless	PC Pin	Board Mount	0.18 in	Tube	Male	3 PSI	16 V	0 V	25 mV	Wheatstone Bridge	85 °C	-25 °C	Through Hole	Vented Gauge
