ADA4500-2 Series
Manufacturer: Analog Devices Inc./Maxim Integrated
Beta
⌘K
10 MHZ, 14.5 NV/√HZ, RAIL-TO-RAIL I/O, ZERO INPUT CROSSOVER DISTORTION AMPLIFIER
| Part | Number of Circuits | Operating Temperature (Max) | Operating Temperature (Min) | Output Type | Current - Input Bias | Package Name | Gain Bandwidth Product | Voltage - Input Offset | Current - Output / Channel | Current - Supply | -3db Bandwidth | Package Width | Package Length | Voltage - Supply Span (Min) | Amplifier Type | Slew Rate | Voltage - Supply Span (Max) | Mounting Type | Package / Case | Contents | Type | Function |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Analog Devices Inc./Maxim Integrated | 2 | 125 °C | -40 °C | Rail-to-Rail | 0.7 pA | 8-MSOP 8-TSSOP 8-MSOP | 10 MHz | 120 µV | 75 mA | 1.5 mA | 19.2 MHz | 3 mm | 0.118 in | 2.7 V | General Purpose | 5.5 V/µs | 5.5 V | Surface Mount | ||||
 Analog Devices Inc./Maxim Integrated | 2 | 125 °C | -40 °C | Rail-to-Rail | 0.7 pA | 8-LFCSP-WD | 10 MHz | 120 µV | 75 mA | 1.5 mA | 19.2 MHz | 3 mm | 3 mm | 2.7 V | General Purpose | 5.5 V/µs | 5.5 V | Surface Mount | 8-WFDFN Exposed Pad CSP | |||
Analog Devices Inc./Maxim Integrated | 2 | 125 °C | -40 °C | Rail-to-Rail | 0.7 pA | 8-MSOP 8-TSSOP 8-MSOP | 10 MHz | 120 µV | 75 mA | 1.5 mA | 19.2 MHz | 3 mm | 0.118 in | 2.7 V | General Purpose | 5.5 V/µs | 5.5 V | Surface Mount | ||||
Analog Devices Inc./Maxim Integrated | 2 | 125 °C | -40 °C | Rail-to-Rail | 0.7 pA | 8-MSOP 8-TSSOP 8-MSOP | 10 MHz | 120 µV | 75 mA | 1.5 mA | 19.2 MHz | 3 mm | 0.118 in | 2.7 V | General Purpose | 5.5 V/µs | 5.5 V | Surface Mount | ||||
 Analog Devices Inc./Maxim Integrated | Board | Amplifier | Filter |
