AD8313 Series

Catalog

LOGARITHMIC DETECTOR/CONTROLLER, 100 MHZ TO 2.5 GHZ, -65 TO 0 DBM, 5.5 V, -40 TO 85 °C, MSOP-8

Part	Package Name	RF Type	Input Level (Min)	Input Level (Max)	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Frequency (Min)	Frequency (Max)	Package Width	Package Length	Accuracy	Current - Supply	Mounting Type	For Use With/Related Products	Supplied Contents	Contents	Utilized IC / Part	Type
Analog Devices Inc./Maxim Integrated AD8313ARMZ	8-MSOP 8-TSSOP 8-MSOP	8.2.16 802.11 Radar WiFi WiMAX Wireless LAN	-65 dBm	0 dBm	5.5 V	2.7 V	100 MHz	2.5 GHz	3 mm	0.118 in	1 dB	13.7 mA	Surface Mount
Analog Devices Inc./Maxim Integrated AD8313-EVALZ							100 MHz	2.5 GHz						AD8313	Board(s)	Board	AD8313	Log Detector/Controller
Analog Devices Inc./Maxim Integrated AD8313ARMZ-REEL	8-MSOP 8-TSSOP 8-MSOP	8.2.16 802.11 Radar WiFi WiMAX Wireless LAN	-65 dBm	0 dBm	5.5 V	2.7 V	100 MHz	2.5 GHz	3 mm	0.118 in	1 dB	13.7 mA	Surface Mount
Analog Devices Inc./Maxim Integrated AD8313ARMZ-REEL7	8-MSOP 8-TSSOP 8-MSOP	8.2.16 802.11 Radar WiFi WiMAX Wireless LAN	-65 dBm	0 dBm	5.5 V	2.7 V	100 MHz	2.5 GHz	3 mm	0.118 in	1 dB	13.7 mA	Surface Mount
