D38999/20SD Series
Manufacturer: Amphenol Aerospace Operations
Beta
⌘K
CONN RCPT MALE 12POS GOLD CRIMP
| Part | Orientation | Number of Positions | Contact Finish - Mating | Applications | Connector Type | Mounting Type | Current Rating Options | Fastening Type | Grade | Primary Material | Contact Material | Insert Material | Ingress Protection Description | Ingress Protection IP Rating | Shielding | Termination | Qualification | Shell Finish | Shell Size - Insert (Maximum) | Shell Size - Insert (Minimum) | Shell Size (MIL) | Shell Material | Mounting Feature | Contact Finish Thickness - Mating | Operating Temperature (Max) | Operating Temperature (Min) | Ingress Protection | Material Flammability Rating | Color | Housing Color | Note | Includes Total Count | Includes | Insert Quantity | Type | Contact Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Amphenol Aerospace Operations | A | 12 | Gold | Aviation Marine Military | Male Pins Receptacle | Panel Mount | 13A 7.5A | Threaded | Military | Metal | Copper Alloy | Thermoplastic | Dust Tight Waterproof | IP67 | Shielded | Crimp | MIL-DTL-38999 Series III | Nickel | 97 | 15 | D | Stainless Steel | Flange | 50 µin | 200 °C | -65 °C | ||||||||||
 Amphenol Aerospace Operations | N (Normal) | 19 | Gold | Aerospace Aviation Military | Female Sockets Receptacle | Panel Mount | Threaded | Military | Metal | Copper Alloy | Thermoplastic | Shielded | Crimp | MIL-DTL-38999 Series III | 19 | 15 | D | Flange | 125 °C | -65 °C | Waterproof | UL94 V-0 | ||||||||||||||
Amphenol Aerospace Operations | N (Normal) | 18 | Gold | Aerospace Aviation Military | Female Sockets Receptacle | Panel Mount | Threaded | Military | Metal | Copper Alloy | Thermoplastic | Shielded | Crimp | MIL-DTL-38999 Series III | 18 | 15 | D | Flange | 125 °C | -65 °C | Waterproof | UL94 V-0 | ||||||||||||||
Amphenol Aerospace Operations | A | 15 | Gold | Aviation Marine Military | Male Pins Receptacle | Panel Mount | 13A 7.5A | Threaded | Military | Metal | Copper Alloy | Thermoplastic | Dust Tight Waterproof | IP67 | Shielded | Crimp | MIL-DTL-38999 Series III | Nickel | 15 | 15 | D | Stainless Steel | Flange | 50 µin | 200 °C | -65 °C | ||||||||||
 Amphenol Aerospace Operations | N (Normal) | 19 | Gold | Aerospace Aviation Military | Male Pins Receptacle | Panel Mount | Threaded | Military | Metal | Copper Alloy | Thermoplastic | Shielded | Crimp | MIL-DTL-38999 Series III | Nickel | 19 | 15 | D | Stainless Steel | Flange | 125 °C | -65 °C | Waterproof | UL94 V-0 | Silver | |||||||||||
 Amphenol Aerospace Operations | N (Normal) | 15 | Gold | Aerospace Aviation Military | Female Sockets Receptacle | Panel Mount | Threaded | Military | Metal | Copper Alloy | Thermoplastic | Shielded | Crimp | MIL-DTL-38999 Series III | Nickel | 15 | 15 | D | Stainless Steel | Flange | 125 °C | -65 °C | Waterproof | UL94 V-0 | Silver | |||||||||||
 Amphenol Aerospace Operations | N (Normal) | 5 | Receptacle Housing | Panel Mount | Threaded | Metal | Thermoplastic | D | Flange | 200 °C | -65 °C | Waterproof | UL94 V-0 | Silver | Contacts Not Included | 1 pcs 1 pc | Insert Shell | 1 pcs | For Female Sockets | Crimp | ||||||||||||||||
Amphenol Aerospace Operations | A | 12 | Gold | Aerospace Aviation Marine Military | Male Pins Receptacle | Panel Mount | 13A 7.5A | Threaded | Metal | Copper Alloy | Shielded | Crimp | Nickel | 97 | 15 | D | Stainless Steel | Flange | 50 µin | 200 °C | -65 °C | Environment Resistant | Silver |
