ADCMP607 Series

Catalog

IC COMPARATOR 1 W/LATCH 12LFCSP

Part	Current - Quiescent (Max)	Number of Elements	Hysteresis	Voltage - Supply (Single) Maximum	Supply Configuration	Voltage - Supply (Single) Minimum	PSRR (Typ)	CMRR (Typ)	Package / Case	Propagation Delay (Max)	Output Type	Package Name	Package Width	Package Length	Current - Input Bias (Max)	Operating Temperature (Max)	Operating Temperature (Min)	Mounting Type	Type	Voltage - Input Offset (Max)	Current - Output (Typ)	Supplied Contents	Function	Contents	Primary Attributes	Embedded	Secondary Attributes	Utilized IC / Part
Analog Devices Inc./Maxim Integrated ADCMP607BCPZ-R2	1.5 mA	1	100 µV	5.5 V	Dual Single	2.5 V	50 dB	50 dB	12-WFQFN Exposed Pad	2.1 ns	CML	12-LFCSP-WQ	3 mm	3 mm	5 µA	125 °C	-40 °C	Surface Mount	with Latch	5 mV	50 mA
Analog Devices Inc./Maxim Integrated ADCMP607BCPZ-WP	1.5 mA	1	100 µV	5.5 V	Dual Single	2.5 V	50 dB	50 dB	12-WFQFN Exposed Pad	2.1 ns	CML	12-LFCSP-WQ	3 mm	3 mm	5 µA	125 °C	-40 °C	Surface Mount	with Latch	5 mV	50 mA
Analog Devices Inc./Maxim Integrated EVAL-ADCMP607BCPZ																			Linear			Board(s)	Comparator Single	Board	CML Compatible Outputs	No	Latch Enable and Shutdown Pins	ADCMP607
Analog Devices Inc./Maxim Integrated ADCMP607BCPZ-R7	1.5 mA	1	100 µV	5.5 V	Dual Single	2.5 V	50 dB	50 dB	12-WFQFN Exposed Pad	2.1 ns	CML	12-LFCSP-WQ	3 mm	3 mm	5 µA	125 °C	-40 °C	Surface Mount	with Latch	5 mV	50 mA
