MIC4420 Series

Catalog

IC GATE DRVR LOW-SIDE 8DIP

Part	Gate Type	Fall Time (Typ)	Rise Time (Typ)	Operating Temperature (Min)	Operating Temperature (Max)	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Number of Drivers	Gate Channel	Channel Type	Input Type	Mounting Type	Logic Voltage - VIH	Logic Voltage - VIL	Package Name	Current - Peak Output (Source)	Current - Peak Output (Sink)	Driven Configuration	Package Length	Package Width	Package / Case
Microchip Technology MIC4420BN	MOSFET N-Channel P-Channel MOSFET	13 ns	12 ns	-40 °C	150 °C	18 V	4.5 V	1	N-Channel P-Channel	Single	Non-Inverting	Through Hole	2.4 V	0.8 V	8-DIP 8-PDIP	6 A	6 A	Low-Side	0.3 in	7.62 mm
Microchip Technology MIC4420YMM	MOSFET	13 ns	12 ns	-40 °C	150 °C	18 V	4.5 V	1	N-Channel P-Channel	Single	Non-Inverting	Surface Mount	2.4 V	0.8 V	8-MSOP 8-TSSOP 8-MSOP	6 A	6 A	Low-Side	0.118 in	3 mm
Microchip Technology MIC4420YN	MOSFET	13 ns	12 ns	-40 °C	150 °C	18 V	4.5 V	1	N-Channel P-Channel	Single	Non-Inverting	Through Hole	2.4 V	0.8 V	8-DIP 8-PDIP	6 A	6 A	Low-Side	0.3 in	7.62 mm
Microchip Technology MIC4420YM	MOSFET N-Channel P-Channel MOSFET	13 ns	12 ns	-40 °C	150 °C	18 V	4.5 V	1	N-Channel P-Channel	Single	Non-Inverting	Surface Mount	2.4 V	0.8 V	8-SOIC	6 A	6 A	Low-Side	0.154 in	3.9 mm
Microchip Technology MIC4420ZM-TR	MOSFET N-Channel P-Channel MOSFET	13 ns	12 ns	0 °C	150 °C	18 V	4.5 V	1	N-Channel P-Channel	Single	Non-Inverting	Surface Mount	2.4 V	0.8 V	8-SOIC	6 A	6 A	Low-Side	0.154 in	3.9 mm
Microchip Technology MIC4420CM-TR	MOSFET N-Channel P-Channel MOSFET	13 ns	12 ns	0 °C	150 °C	18 V	4.5 V	1	N-Channel P-Channel	Single	Non-Inverting	Surface Mount	2.4 V	0.8 V	8-SOIC	6 A	6 A	Low-Side	0.154 in	3.9 mm
Microchip Technology MIC4420CM	MOSFET N-Channel P-Channel MOSFET	13 ns	12 ns	0 °C	150 °C	18 V	4.5 V	1	N-Channel P-Channel	Single	Non-Inverting	Surface Mount	2.4 V	0.8 V	8-SOIC	6 A	6 A	Low-Side	0.154 in	3.9 mm
Microchip Technology MIC4420ZM	MOSFET N-Channel P-Channel MOSFET	13 ns	12 ns	0 °C	150 °C	18 V	4.5 V	1	N-Channel P-Channel	Single	Non-Inverting	Surface Mount	2.4 V	0.8 V	8-SOIC	6 A	6 A	Low-Side	0.154 in	3.9 mm
Microchip Technology MIC4420ZT	MOSFET N-Channel P-Channel MOSFET	13 ns	12 ns	0 °C	150 °C	18 V	4.5 V	1	N-Channel P-Channel	Single	Non-Inverting	Through Hole	2.4 V	0.8 V	TO-220-5	6 A	6 A	Low-Side			TO-220-5
Microchip Technology MIC4420YMM-TR	MOSFET N-Channel P-Channel MOSFET	13 ns	12 ns	-40 °C	150 °C	18 V	4.5 V	1	N-Channel P-Channel	Single	Non-Inverting	Surface Mount	2.4 V	0.8 V	8-MSOP 8-TSSOP 8-MSOP	6 A	6 A	Low-Side	0.118 in	3 mm
