AD8051 Series

Low Cost, High Speed, Single, Rail-to-Rail Amplifier

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

Low Cost, High Speed, Single, Rail-to-Rail Amplifier

Part	Voltage - Supply Span (Max)	Current - Supply	Current - Input Bias	Voltage - Supply Span (Min)	Number of Circuits	Package Name	Mounting Type	Package Length	Package Width	Current - Output / Channel	Operating Temperature (Max)	Operating Temperature (Min)	-3db Bandwidth	Output Type	Amplifier Type	Slew Rate	Voltage - Input Offset	Supplied Contents	Board Type	Channels per IC (Single)	Channels per IC (Type)	Channels per IC (Count)	Contents	Utilized IC / Part
Analog Devices Inc./Maxim Integrated AD8051AR-REEL7	12 V	4.8 mA	1.4 µA	3 V	1	8-SOIC	Surface Mount	0.154 in	3.9 mm	45 mA	125 °C	-40 °C	110 MHz	Rail-to-Rail	Voltage Feedback	170 V/µs	1.8 mV
Analog Devices Inc./Maxim Integrated AD8051ART-EBZ															Voltage Feedback			Board(s)	Bare (Unpopulated)	1	Single	1	Unpopulated (Bare) Board	SOT-23-5 Package
Analog Devices Inc./Maxim Integrated AD8051ARTZ-R2	12 V	4.8 mA	1.4 µA	3 V	1	SOT-23-5	Surface Mount			45 mA	125 °C	-40 °C	110 MHz	Rail-to-Rail	Voltage Feedback	170 V/µs	1.8 mV
Analog Devices Inc./Maxim Integrated AD8051ART-R2	12 V	4.8 mA	1.4 µA	3 V	1	SOT-23-5	Surface Mount			45 mA	125 °C	-40 °C	110 MHz	Rail-to-Rail	Voltage Feedback	170 V/µs	1.8 mV
Analog Devices Inc./Maxim Integrated AD8051ARZ	12 V	4.8 mA	1.4 µA	3 V	1	8-SOIC	Surface Mount	0.154 in	3.9 mm	45 mA	125 °C	-40 °C	110 MHz	Rail-to-Rail	Voltage Feedback	170 V/µs	1.8 mV
Analog Devices Inc./Maxim Integrated AD8051AR	12 V	4.8 mA	1.4 µA	3 V	1	8-SOIC	Surface Mount	0.154 in	3.9 mm	45 mA	125 °C	-40 °C	110 MHz	Rail-to-Rail	Voltage Feedback	170 V/µs	1.8 mV
Analog Devices Inc./Maxim Integrated AD8051ART-REEL7	12 V	4.8 mA	1.4 µA	3 V	1	SOT-23-5	Surface Mount			45 mA	125 °C	-40 °C	110 MHz	Rail-to-Rail	Voltage Feedback	170 V/µs	1.8 mV
Analog Devices Inc./Maxim Integrated AD8051ARTZ-REEL7	12 V	4.8 mA	1.4 µA	3 V	1	SOT-23-5	Surface Mount			45 mA	125 °C	-40 °C	110 MHz	Rail-to-Rail	Voltage Feedback	170 V/µs	1.8 mV
Analog Devices Inc./Maxim Integrated AD8051ARTZ-REEL	12 V	4.8 mA	1.4 µA	3 V	1	SOT-23-5	Surface Mount			45 mA	125 °C	-40 °C	110 MHz	Rail-to-Rail	Voltage Feedback	170 V/µs	1.8 mV
Analog Devices Inc./Maxim Integrated AD8051AR-REEL	12 V	4.8 mA	1.4 µA	3 V	1	8-SOIC	Surface Mount	0.154 in	3.9 mm	45 mA	125 °C	-40 °C	110 MHz	Rail-to-Rail	Voltage Feedback	170 V/µs	1.8 mV

Catalog

Low Cost, High Speed, Single, Rail-to-Rail Amplifier

Description

The AD8051 (single), AD8052 (dual) and AD8054 (quad) are low cost, high speed, voltage feedback amplifiers. The amplifiers operate on +3 V, +5 V or ±5 V supplies at low supply current. They have true single-supply capability with an input voltage range extending 200 mV below the negative rail and within 1 V of the positive rail.Despite their low cost, the AD8051/AD8052/AD8054 provide excellent overall performance and versatility. The output voltage swings to within 25 mV of each rail, providing the maximum output dynamic range with excellent overdrive recovery.The AD8051/AD8052/AD8054 are well suited for video electronics, cameras, video switchers, or any high speed portable equipment. Low distortion and fast settling make them ideal for active filter applications.The AD8051/AD8052 in the 8-lead SOIC, the AD8052 in the MSOP, the AD8054 in the 14-lead SOIC, and the 14-lead TSSOP packages are available in the extended temperature range of −40°C to +125°C.ApplicationsActive filtersAnalog-to-digital driversClock bufferConsumer videoProfessional camerasCCD imaging systemsCD/DVD ROMs
