AD8564 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

IC COMPARATOR 4 GEN PUR 16SOIC

Part	Type	PSRR (Typ)	CMRR (Typ)	Package Width	Package Name	Package Length	Propagation Delay (Max)	Number of Elements	Operating Temperature (Min)	Operating Temperature (Max)	Voltage - Input Offset (Max)	Output Type	Mounting Type	Current - Quiescent (Max)	Current - Input Bias (Max)
Analog Devices Inc./Maxim Integrated AD8564AR-REEL	General Purpose Standard (General Purpose)	80 dB	85 dB	3.9 mm	16-SOIC	0.154 in	9.8 ns	4	-40 °C	85 °C	7 mV	CMOS TTL	Surface Mount	14mA 7mA	4 µA
Analog Devices Inc./Maxim Integrated AD8564ARZ	General Purpose Standard (General Purpose)	80 dB	85 dB	3.9 mm	16-SOIC	0.154 in	9.8 ns	4	-40 °C	85 °C	7 mV	CMOS TTL	Surface Mount	14mA 7mA	4 µA
Analog Devices Inc./Maxim Integrated AD8564ARZ-REEL	General Purpose Standard (General Purpose)	80 dB	85 dB	3.9 mm	16-SOIC	0.154 in	9.8 ns	4	-40 °C	85 °C	7 mV	CMOS TTL	Surface Mount	14mA 7mA	4 µA
Analog Devices Inc./Maxim Integrated AD8564ARU-REEL	General Purpose Standard (General Purpose)	80 dB	85 dB	4.4 mm	16-TSSOP	0.173 in	9.8 ns	4	-40 °C	85 °C	7 mV	CMOS TTL	Surface Mount	14mA 7mA	4 µA
Analog Devices Inc./Maxim Integrated AD8564ARUZ-REEL	General Purpose Standard (General Purpose)	80 dB	85 dB	4.4 mm	16-TSSOP	0.173 in	9.8 ns	4	-40 °C	85 °C	7 mV	CMOS TTL	Surface Mount	14mA 7mA	4 µA
Analog Devices Inc./Maxim Integrated AD8564AN	General Purpose Standard (General Purpose)	80 dB	85 dB	7.62 mm	16-DIP 16-PDIP	0.3 in	9.8 ns	4	-40 °C	85 °C	7 mV	CMOS TTL	Through Hole	14mA 7mA	4 µA
Analog Devices Inc./Maxim Integrated AD8564ARZ-REEL7	General Purpose Standard (General Purpose)	80 dB	85 dB	3.9 mm	16-SOIC	0.154 in	9.8 ns	4	-40 °C	85 °C	7 mV	CMOS TTL	Surface Mount	14mA 7mA	4 µA
