C091 11H004 Series
Manufacturer: McGill Microwave Systems
Beta
⌘K
MALE CABLE CONNECTOR WITH INTERN
| Part | Ingress Protection IP Rating | Ingress Protection Description | Shell Finish | Insert Material | Number of Positions | Contact Size | Operating Temperature (Max) | Operating Temperature (Min) | Shell Material | Note | Contact Shape | Features | Shell Size - Insert | Type | Mounting Type | Connector Type | Fastening Type | Orientation | Material Flammability Rating | Shielding | Contact Type | Housing Color |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 McGill Microwave Systems | IP68 | Dust Tight Waterproof | Nickel | Thermoplastic | 4 | 1.5 mm | 100 °C | -40 °C | Zinc Die Cast | Contacts Not Included | Circular | Backshell Cable Clamp Coupling Nut | M16-4 | For Male Pins | Free Hanging (In-Line) | Plug Housing | Threaded | Keyed | UL94 V-0 | Shielded | Crimp | Silver |
