AD9648 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

2-CHANNEL DUAL ADC PIPELINED 125MSPS 14-BIT PARALLEL/LVDS 64-PIN LFCSP EP T/R

Part	Sampling Rate (Per Second)	Data Interface	Ratio - ADC	Ratio - S/H	Package / Case	Configuration	Operating Temperature (Min)	Operating Temperature (Max)	Architecture	Reference Type	Input Type	Voltage - Supply, Digital (Min)	Voltage - Supply, Digital (Max)	Number of Inputs	Voltage - Supply, Analog (Max)	Voltage - Supply, Analog (Min)	Number of Bits	Mounting Type	Features	Number of A/D Converters	Package Length	Package Name	Package Width	Supplied Contents	Input Voltage (Value)	Contents	Utilized IC / Part
Analog Devices Inc./Maxim Integrated AD9648BCPZRL7-125	125 MHz	LVDS - Parallel Parallel	1	1	64-VFQFN Exposed Pad CSP	S/H-ADC	-40 °C	85 °C	Pipelined	External Internal	Differential	1.7 V	1.9 V	2	1.9 V	1.7 V	14 bits	Surface Mount	Simultaneous Sampling	2 count	9 mm	64-LFCSP-VQ	9 mm
Analog Devices Inc./Maxim Integrated AD9648-125EBZ		Serial															14 bits			2 count				Board(s)	2 Vpp	Board	AD9648
Analog Devices Inc./Maxim Integrated AD9648TCPZ-125-EP	125 MHz	LVDS - Parallel Parallel	1	1	64-WFQFN Exposed Pad CSP	S/H-ADC	-55 °C	125 °C	Pipelined	External Internal	Differential	1.7 V	1.9 V	2	1.9 V	1.7 V	14 bits	Surface Mount	Simultaneous Sampling	2 count	9 mm	64-LFCSP	9 mm
Analog Devices Inc./Maxim Integrated AD9648TCPZ125EPRL7	125 MHz	LVDS - Parallel Parallel	1	1	64-WFQFN Exposed Pad CSP	S/H-ADC	-55 °C	125 °C	Pipelined	External Internal	Differential	1.7 V	1.9 V	2	1.9 V	1.7 V	14 bits	Surface Mount	Simultaneous Sampling	2 count	9 mm	64-LFCSP	9 mm
Analog Devices Inc./Maxim Integrated AD9648BCPZRL7-105	105 MHz	LVDS - Parallel Parallel	1	1	64-VFQFN Exposed Pad CSP	S/H-ADC	-40 °C	85 °C	Pipelined	External Internal	Differential	1.7 V	1.9 V	2	1.9 V	1.7 V	14 bits	Surface Mount	Simultaneous Sampling	2 count	9 mm	64-LFCSP-VQ	9 mm
Analog Devices Inc./Maxim Integrated AD9648BCPZ-125	125 MHz	LVDS - Parallel Parallel	1	1	64-VFQFN Exposed Pad CSP	S/H-ADC	-40 °C	85 °C	Pipelined	External Internal	Differential	1.7 V	1.9 V	2	1.9 V	1.7 V	14 bits	Surface Mount	Simultaneous Sampling	2 count	9 mm	64-LFCSP-VQ	9 mm
Analog Devices Inc./Maxim Integrated AD9648BCPZ-105	105 MHz	LVDS - Parallel Parallel	1	1	64-VFQFN Exposed Pad CSP	S/H-ADC	-40 °C	85 °C	Pipelined	External Internal	Differential	1.7 V	1.9 V	2	1.9 V	1.7 V	14 bits	Surface Mount	Simultaneous Sampling	2 count	9 mm	64-LFCSP-VQ	9 mm
