ADAU1401 Series

Catalog

SIGMADSP 28-/56-BIT AUDIO PROCESSOR WITH TWO ADCS AND FOUR DACS

Part	On-Chip RAM	Interface	Clock Rate (Frequency)	Package / Case	Operating Temperature (Max)	Operating Temperature (Min)	Package Length	Package Name	Package Width	Mounting Type	Voltage - I/O	Voltage - Core	Grade	Type	Supplied Contents	Primary Attributes	Number of DACs	Resolution	Number of ADCs	Contents	Secondary Attributes	Utilized IC / Part	Function	Embedded
Analog Devices Inc./Maxim Integrated ADAU1401AWBSTZ	12 kB	I2C SPI	50 MHz	48-LQFP	105 °C	-40 °C	7 mm	48-LQFP	7 mm	Surface Mount	3.3 V	1.8 V	Automotive	Sigma
Analog Devices Inc./Maxim Integrated ADAU1401AWBSTZ-RL	12 kB	I2C SPI	50 MHz	48-LQFP	105 °C	-40 °C	7 mm	48-LQFP	7 mm	Surface Mount	3.3 V	1.8 V	Automotive	Sigma
Analog Devices Inc./Maxim Integrated EVAL-ADAU1401AEBZ														Audio	Board(s) Cable(s) Power Supply	2 ADCs 28-/56-Bit Audio Processor @ 50-MIPS 4 DACs	4 count	56 Bit	2 count	Board Cable Power Supply	Bass Enhancement Crossover Delay Equalization Etc. Multiband Dynamics Processing	ADAU1401A	CODEC	DSP Yes
Analog Devices Inc./Maxim Integrated ADAU1401YSTZ	12 kB	I2C SPI	50 MHz	48-LQFP	105 °C	-40 °C	7 mm	48-LQFP	7 mm	Surface Mount	3.3 V	1.8 V		Sigma
Analog Devices Inc./Maxim Integrated EVAL-ADAU1401EBZ														Audio	Board(s) Cable(s) Power Supply	2 ADCs 28-/56-Bit Audio Processor @ 50-MIPS 4 DACs	4 count	56 Bit	2 count	Board Cable Power Supply	Bass Enhancement Crossover Delay Equalization Etc. Multiband Dynamics Processing	ADAU1401	CODEC	DSP Yes
