ADN2815 Series

Catalog

CONTINUOUS RATE 10 MB/S TO 1.25 GB/S CLOCK AND DATA RECOVERY IC

Part	Input Ratio	Output Ratio	Number of Circuits	Output	Package Width	Package Name	Package Length	Main Purpose	Frequency - Max	Input	Differential Input	Differential Output	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Operating Temperature (Min)	Operating Temperature (Max)	Package / Case	PLL	Mounting Type
Analog Devices Inc./Maxim Integrated ADN2815ACPZ	1	2	1	LVDS	5 mm	32-LFCSP-WQ	5 mm	SONET/SDH	1.25 GHz	CML	Yes	Yes	3.6 V	3 V	-40 °C	85 °C	32-WFQFN Exposed Pad CSP	Yes	Surface Mount
Analog Devices Inc./Maxim Integrated ADN2815ACPZ-500RL7	1	2	1	LVDS	5 mm	32-LFCSP-WQ	5 mm	SONET/SDH	1.25 GHz	CML	Yes	Yes	3.6 V	3 V	-40 °C	85 °C	32-WFQFN Exposed Pad CSP	Yes	Surface Mount
Analog Devices Inc./Maxim Integrated ADN2815ACPZ-RL7	1	2	1	LVDS	5 mm	32-LFCSP-WQ	5 mm	SONET/SDH	1.25 GHz	CML	Yes	Yes	3.6 V	3 V	-40 °C	85 °C	32-WFQFN Exposed Pad CSP	Yes	Surface Mount
