AD9644 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

14-BIT, 80 MSPS/155 MSPS, 1.8V DUAL, SERIAL OUTPUT A/D CONVERTER

Part	Package Width	Package Name	Package Length	Sampling Rate (Per Second)	Data Interface	Mounting Type	Reference Type	Number of Bits	Input Type	Package / Case	Architecture	Voltage - Supply, Analog (Max)	Voltage - Supply, Analog (Min)	Number of A/D Converters	Configuration	Voltage - Supply, Digital (Min)	Voltage - Supply, Digital (Max)	Features	Number of Inputs	Operating Temperature (Min)	Operating Temperature (Max)	Ratio - ADC	Ratio - S/H
Analog Devices Inc./Maxim Integrated AD9644BCPZRL7-80	7 mm	48-LFCSP-VQ	7 mm	80 MHz	JESD204A	Surface Mount	Internal	14 bits	Differential	48-VFQFN Exposed Pad CSP	Pipelined	1.9 V	1.7 V	2 count	S/H-ADC	1.7 V	1.9 V	Simultaneous Sampling	2	-40 °C	85 °C	1	1
Analog Devices Inc./Maxim Integrated AD9644CCPZ-80	7 mm	48-LFCSP-VQ	7 mm	80 MHz	JESD204A	Surface Mount	Internal	14 bits	Differential	48-VFQFN Exposed Pad CSP	Pipelined	1.9 V	1.7 V	2 count	S/H-ADC	1.7 V	1.9 V	Simultaneous Sampling	2	-40 °C	85 °C	1	1
Analog Devices Inc./Maxim Integrated AD9644CCPZRL7-80	7 mm	48-LFCSP-VQ	7 mm	80 MHz	JESD204A	Surface Mount	Internal	14 bits	Differential	48-VFQFN Exposed Pad CSP	Pipelined	1.9 V	1.7 V	2 count	S/H-ADC	1.7 V	1.9 V	Simultaneous Sampling	2	-40 °C	85 °C	1	1
Analog Devices Inc./Maxim Integrated AD9644BCPZ-80	7 mm	48-LFCSP-VQ	7 mm	80 MHz	JESD204A	Surface Mount	Internal	14 bits	Differential	48-VFQFN Exposed Pad CSP	Pipelined	1.9 V	1.7 V	2 count	S/H-ADC	1.7 V	1.9 V	Simultaneous Sampling	2	-40 °C	85 °C	1	1
Analog Devices Inc./Maxim Integrated AD9644BCPZRL7-155	7 mm	48-LFCSP-VQ	7 mm	155 MHz	JESD204A	Surface Mount	Internal	14 bits	Differential	48-VFQFN Exposed Pad CSP	Pipelined	1.9 V	1.7 V	2 count	S/H-ADC	1.7 V	1.9 V	Simultaneous Sampling	2	-40 °C	85 °C	1	1
Analog Devices Inc./Maxim Integrated AD9644BCPZ-155	7 mm	48-LFCSP-VQ	7 mm	155 MHz	JESD204A	Surface Mount	Internal	14 bits	Differential	48-VFQFN Exposed Pad CSP	Pipelined	1.9 V	1.7 V	2 count	S/H-ADC	1.7 V	1.9 V	Simultaneous Sampling	2	-40 °C	85 °C	1	1
