Power Diode Discretes-Rectifier GUFP
Description
AI
The Three Phase Bridge series comes in a high variety of packages and breakdown voltages up to 2200V.
Beta
⌘K
Power Diode Discretes-Rectifier GUFP
Power Diode Discretes-Rectifier GUFP
| Part | Mounting Type | Operating Temperature (Max) | Operating Temperature (Min) | Package Name | Package / Case | Diode Type | Technology | Current - Average Rectified (Io) | Voltage - Peak Reverse (Max) | Voltage - Forward (Vf) (Max) | Current - Reverse Leakage |
|---|---|---|---|---|---|---|---|---|---|---|---|
 LITTELFUSE | Through Hole | 175 °C | -40 °C | GUFP | 5-SIP | Three Phase | Standard | 40 A | 1.6 kV | 1.28 V | 40 µA |
LITTELFUSE | Through Hole | 175 °C | -40 °C | GUFP | 5-SIP | Three Phase | Standard | 40 A | 800 V | 1.28 V | 40 µA |
LITTELFUSE | Through Hole | 175 °C | -40 °C | GUFP | 5-SIP | Three Phase | Standard | 40 A | 1200 V | 1.28 V | 40 µA |
