NJ2-12 Series
Manufacturer: Pepperl+Fuchs, Inc.
Beta
⌘K
INDUCTIVE SEN 2MM NAMUR
| Part | Operating Temperature (Min) | Operating Temperature (Max) | Termination Style | Material - Body | Voltage - Supply | Package / Case | Sensor Type | Indicator | Shielding | Ingress Protection | Sensing Distance | Output Type | Voltage - Supply (Maximum) | Voltage - Supply (Minimum) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Pepperl+Fuchs, Inc. | -25 °C | 100 °C | Cable | Polybutylene Terephthalate (PBT) | 8.2 V | Cylinder Threaded - M12 | Inductive | No Indicator | Unshielded | IP66 IP68 | 0.079 " | 2-Wire SCR-NC | ||
 Pepperl+Fuchs, Inc. | -25 °C | 100 °C | Connector | Stainless Steel | 8.2 V | Cylinder Threaded - M12 | Inductive | No Indicator | Unshielded | IP67 | 0.079 " | 2-Wire SCR-NC | ||
 Pepperl+Fuchs, Inc. | -25 °C | 100 °C | Cable | Stainless Steel | 8.2 V | Cylinder Threaded - M12 | Inductive | No Indicator | Unshielded | IP66 IP67 | 0.079 " | 2-Wire SCR-NC | ||
 Pepperl+Fuchs, Inc. | -25 °C | 70 °C | Connector | Stainless Steel | Cylinder Threaded - M12 | Inductive | LED | Unshielded | IP67 | 0.079 " | 3-Wire PNP-NO | 60 V | 10 VDC |
