ADIN6310 Series

The ADIN6310 is a 6-port Gigabit Ethernet, time sensitive networking (TSN) switch with integrated security designed for industrial Ethernet applications. Each port can be configured to operate at different speeds. This switch has uncommitted media access controller (MAC) interfaces and can be paired with Analog Devices, Inc., physical (PHY) layer devices, such asADIN1100,ADIN1200, andADIN1300, to form a low power, low latency system. Four serial gigabit media independent interface (SGMII) and serializer/deserializer (serdes) interfaces allow backplane connections, connectivity to small form factor (SFP) modules and cascade switches. The switch supports the suite of IEEE 802.1Q time sensitive networking bridging features required by IEEE 60802 standard providing quality of service (QoS) for latency sensitive streams. The device also includes hardware capability to support parallel redundancy protocol (PRP) or high availability seamless redundancy (HSR) redundancy protocols, thereby offloading the host processor.APPLICATIONSFactory and process automationMotion control, robots, and cobotsEnergy automationTransportationInstrumentationBuilding automation
