AD9528 Series

Catalog

JESD204B/JESD204C CLOCK GENERATOR WITH 14 LVDS/HSTL OUTPUTS

Part	Mounting Type	Operating Temperature (Min)	Operating Temperature (Max)	Voltage - Supply (Minimum)	Voltage - Supply (Maximum)	Multiplier	Divider	Output Ratio	Input Ratio	Number of Circuits	Frequency - Max	Package Length	Package Name	Package Width	Differential Input	Differential Output	Output	Package / Case	Input	PLL	Supplied Contents	Contents	Type	Primary Attributes	Function	Utilized IC / Part	Secondary Attributes
Analog Devices Inc./Maxim Integrated AD9528BCPZ	Surface Mount	-40 °C	85 °C	3.135 V	3.465 V	No	Yes	14	2	1	1.25 GHz	10 mm	72-LFCSP-VQ	10 mm	Yes	Yes	HSTL LVDS	72-VFQFN Exposed Pad CSP	CMOS HSTL LVDS	Yes with Bypass
Analog Devices Inc./Maxim Integrated AD9528BCPZ-REEL7	Surface Mount	-40 °C	85 °C	3.135 V	3.465 V	No	Yes	14	2	1	1.25 GHz	10 mm	72-LFCSP-VQ	10 mm	Yes	Yes	HSTL LVDS	72-VFQFN Exposed Pad CSP	CMOS HSTL LVDS	Yes with Bypass
Analog Devices Inc./Maxim Integrated AD9528/PCBZ																					Board(s)	Board	Timing	14-Channel	Clock Generator	AD9528	Graphical User Interface (GUI)
