ADF4371 Series

Catalog

EVALUATION BOARD, REV. 2

Part	Supplied Contents	Primary Attributes	Secondary Attributes	Utilized IC / Part	Function	Type	Contents	Mounting Type	Number of Circuits	Differential Input	Differential Output	Input	Output	Input Ratio	Output Ratio	PLL	Operating Temperature (Min)	Operating Temperature (Max)	Package / Case	Package Name	Package Length	Package Width	Divider	Multiplier	Frequency - Max	Voltage - Supply (Minimum)	Voltage - Supply (Maximum)
Analog Devices Inc./Maxim Integrated EV-ADF4371SD2Z	Board(s)	Single Fractional-N and Integer-N PLL with VCO	Graphical User Interface (GUI)	ADF4371	Frequency Synthesizer	Timing	Board
Analog Devices Inc./Maxim Integrated ADF4371BCCZ-RL7						Integer N Synthesizer (RF)		Surface Mount	1	Yes	Yes	CMOS ECL	Clock	1	5	Yes	-40 °C	105 °C	48-TFLGA Exposed Pad	48-LGA	7 mm	7 mm	Yes	Yes	32 GHz	3.15 V	3.45 V
Analog Devices Inc./Maxim Integrated ADF4371BCCZ						Integer N Synthesizer (RF)		Surface Mount	1	Yes	Yes	CMOS ECL	Clock	1	5	Yes	-40 °C	105 °C	48-TFLGA Exposed Pad	48-LGA	7 mm	7 mm	Yes	Yes	32 GHz	3.15 V	3.45 V
