AD9694 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

QUAD 14-BIT, 500 MSPS, 1.2 V/2.5 V ANALOG-TO-DIGITAL CONVERTER

Part	Package Length	Package Name	Package Width	Sampling Rate (Per Second)	Voltage - Supply, Analog (Range 2 Min)	Voltage - Supply, Analog (Range 1 Min)	Voltage - Supply, Analog (Range 3 Min)	Voltage - Supply, Analog (Range 2 Max)	Voltage - Supply, Analog (Range 1 Max)	Voltage - Supply, Analog (Range 3 Max)	Voltage - Supply, Digital (Max)	Voltage - Supply, Digital (Min)	Number of Inputs	Input Type	Configuration	Reference Type	Architecture	Package / Case	Operating Temperature (Min)	Operating Temperature (Max)	Number of A/D Converters	Number of Bits	Mounting Type	Data Interface	Features	Ratio - ADC	Ratio - S/H	Supplied Contents	Input Voltage (Value)	Power (Typ)	Utilized IC / Part	Contents
Analog Devices Inc./Maxim Integrated AD9694BCPZ-500	10 mm	72-LFCSP-VQ	10 mm	500 MHz	1.71 V	0.95 V	2.44 V	1.89 V	1 V	2.56 V	1 V	0.95 V	4	Differential	S/H-ADC	Internal	Pipelined	72-VFQFN Exposed Pad CSP	-40 °C	105 °C	4 count	14 bits	Surface Mount	JESD204B	Simultaneous Sampling	1	1
Analog Devices Inc./Maxim Integrated AD9694TCPZ-500-EP	10 mm	72-LFCSP-VQ	10 mm	500 MHz	1.71 V	0.95 V	2.44 V	1.89 V	1 V	2.56 V	1 V	0.95 V	4	Differential	S/H-ADC	External Internal	Pipelined	72-VFQFN Exposed Pad CSP	-55 °C	105 °C	4 count	14 bits	Surface Mount	JESD204B	Simultaneous Sampling	1	1
Analog Devices Inc./Maxim Integrated AD9694BCPZRL7-500	10 mm	72-LFCSP-VQ	10 mm	500 MHz	1.71 V	0.95 V	2.44 V	1.89 V	1 V	2.56 V	1 V	0.95 V	4	Differential	S/H-ADC	Internal	Pipelined	72-VFQFN Exposed Pad CSP	-40 °C	105 °C	4 count	14 bits	Surface Mount	JESD204B	Simultaneous Sampling	1	1
Analog Devices Inc./Maxim Integrated AD9694-500EBZ				500 MHz																	4 count	14 bits		JESD204B Serial				Board(s)	1.8 Vpp	1.66 W	AD9694	Board
