ELVH-100G Series

Catalog

SENSOR 100.08PSIG 0.06" 8DIP

Part	Voltage - Supply	Port Style	Termination Style	Accuracy	Pressure Type	Features	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Maximum Pressure	Package Width	Package Features	Package Name	Package Length	Port Diameter	Port Feature	Port Gender	Mounting Type	Operating Temperature (Max)	Output Type	Operating Pressure	Output Bits	Package / Case
McGill Microwave Systems ELVH-100G-HRRD-C-NAA5	5 VDC	Barbed	PC Pin	0.25 %	Gauge	Temperature Compensated	5.5 V	2.7 V	200 PSI	12.8 mm	Dual Ports Same Side	8-DIP	0.504 in	0.06 in	Dual Tube	Male	Through Hole	50 °C	Analog Voltage	100 PSI
McGill Microwave Systems ELVH-100G-HKNJ-C-N2A4	3.3 V	Needle	J Lead	0.25 %	Gauge	Temperature Compensated	5.5 V	2.7 V	200 PSI					0.11 in	Tube	Male	Surface Mount	50 °C	I2C	100 PSI	14 b	8-SMD J-Lead Top Port
McGill Microwave Systems ELVH-100G-HJJD-C-NAA5	5 VDC		PC Pin	0.25 %	Gauge	Temperature Compensated	5.5 V	2.7 V	250.05 PSI	13.3 mm		8-DIP	0.524 in				Through Hole	50 °C	Analog Voltage	100 PSI
