XCZU11 Series

Catalog

IC SOC CORTEX-A53 1517FCBGA

Part	Number of I/O	Peripherals	Primary Attributes	Logic Elements	Package Width	Package Name	Package Length	Speed	Package / Case	Architecture	Operating Temperature (Max)	Operating Temperature (Min)	RAM Size	Core Processor	Connectivity
AMD / Xilinx XCZU11EG-3FFVB1517E	488	DMA WDT	653K+ Logic Cells Zynq®UltraScale+™ FPGA Zynq®UltraScale+™ FPGA 653K+ Logic Cells	653 K	40 mm	1517-FCBGA	40 mm	1.5 GHz 600 MHz 667 MHz	1517-BBGA FCBGA	FPGA MCU	100 °C	0 °C	256 KB	ARM Mali™-400 MP2 Dual ARM®Cortex™-R5 with CoreSight™ Quad ARM® Cortex®-A53 MPCore™ with CoreSight™	CANbus EBI EMI Ethernet I2C MMC SD SDIO SPI UART USART USB OTG
AMD / Xilinx XCZU11EG-L1FFVC1760I	512	DMA WDT	653K+ Logic Cells Zynq®UltraScale+™ FPGA Zynq®UltraScale+™ FPGA 653K+ Logic Cells	653 K	42.5 mm	1760-FCBGA	42.5 mm	1.2 GHz 500 MHz 600 MHz	1760-BBGA FCBGA	FPGA MCU	100 °C	-40 °C	256 KB	ARM Mali™-400 MP2 Dual ARM®Cortex™-R5 with CoreSight™ Quad ARM® Cortex®-A53 MPCore™ with CoreSight™	CANbus EBI EMI Ethernet I2C MMC SD SDIO SPI UART USART USB OTG
AMD / Xilinx XCZU11EG-1FFVF1517E	464	DMA WDT	653K+ Logic Cells Zynq®UltraScale+™ FPGA Zynq®UltraScale+™ FPGA 653K+ Logic Cells	653 K	40 mm	1517-FCBGA	40 mm	1.2 GHz 500 MHz 600 MHz	1517-BBGA FCBGA	FPGA MCU	100 °C	0 °C	256 KB	ARM Mali™-400 MP2 Dual ARM®Cortex™-R5 with CoreSight™ Quad ARM® Cortex®-A53 MPCore™ with CoreSight™	CANbus EBI EMI Ethernet I2C MMC SD SDIO SPI UART USART USB OTG
AMD / Xilinx XCZU11EG-L2FFVF1517E	464	DMA WDT	653K+ Logic Cells Zynq®UltraScale+™ FPGA Zynq®UltraScale+™ FPGA 653K+ Logic Cells	653 K	40 mm	1517-FCBGA	40 mm	1.3 GHz 533 MHz 600 MHz	1517-BBGA FCBGA	FPGA MCU	100 °C	0 °C	256 KB	ARM Mali™-400 MP2 Dual ARM®Cortex™-R5 with CoreSight™ Quad ARM® Cortex®-A53 MPCore™ with CoreSight™	CANbus EBI EMI Ethernet I2C MMC SD SDIO SPI UART USART USB OTG
AMD / Xilinx XCZU11EG-2FFVC1760E	512	DMA WDT	653K+ Logic Cells Zynq®UltraScale+™ FPGA Zynq®UltraScale+™ FPGA 653K+ Logic Cells	653 K	42.5 mm	1760-FCBGA	42.5 mm	1.3 GHz 533 MHz 600 MHz	1760-BBGA FCBGA	FPGA MCU	100 °C	0 °C	256 KB	ARM Mali™-400 MP2 Dual ARM®Cortex™-R5 with CoreSight™ Quad ARM® Cortex®-A53 MPCore™ with CoreSight™	CANbus EBI EMI Ethernet I2C MMC SD SDIO SPI UART USART USB OTG
AMD / Xilinx XCZU11EG-1FFVB1517E	488	DMA WDT	653K+ Logic Cells Zynq®UltraScale+™ FPGA Zynq®UltraScale+™ FPGA 653K+ Logic Cells	653 K	40 mm	1517-FCBGA	40 mm	1.2 GHz 500 MHz 600 MHz	1517-BBGA FCBGA	FPGA MCU	100 °C	0 °C	256 KB	ARM Mali™-400 MP2 Dual ARM®Cortex™-R5 with CoreSight™ Quad ARM® Cortex®-A53 MPCore™ with CoreSight™	CANbus EBI EMI Ethernet I2C MMC SD SDIO SPI UART USART USB OTG
AMD / Xilinx XCZU11EG-3FFVC1760E	512	DMA WDT	653K+ Logic Cells Zynq®UltraScale+™ FPGA Zynq®UltraScale+™ FPGA 653K+ Logic Cells	653 K	42.5 mm	1760-FCBGA	42.5 mm	1.5 GHz 600 MHz 667 MHz	1760-BBGA FCBGA	FPGA MCU	100 °C	0 °C	256 KB	ARM Mali™-400 MP2 Dual ARM®Cortex™-R5 with CoreSight™ Quad ARM® Cortex®-A53 MPCore™ with CoreSight™	CANbus EBI EMI Ethernet I2C MMC SD SDIO SPI UART USART USB OTG
AMD / Xilinx XCZU11EG-2FFVB1517E	488	DMA WDT	653K+ Logic Cells Zynq®UltraScale+™ FPGA Zynq®UltraScale+™ FPGA 653K+ Logic Cells	653 K	40 mm	1517-FCBGA	40 mm	1.3 GHz 533 MHz 600 MHz	1517-BBGA FCBGA	FPGA MCU	100 °C	0 °C	256 KB	ARM Mali™-400 MP2 Dual ARM®Cortex™-R5 with CoreSight™ Quad ARM® Cortex®-A53 MPCore™ with CoreSight™	CANbus EBI EMI Ethernet I2C MMC SD SDIO SPI UART USART USB OTG
AMD / Xilinx XCZU11EG-L1FFVF1517I	464	DMA WDT	653K+ Logic Cells Zynq®UltraScale+™ FPGA Zynq®UltraScale+™ FPGA 653K+ Logic Cells	653 K	40 mm	1517-FCBGA	40 mm	1.2 GHz 500 MHz 600 MHz	1517-BBGA FCBGA	FPGA MCU	100 °C	-40 °C	256 KB	ARM Mali™-400 MP2 Dual ARM®Cortex™-R5 with CoreSight™ Quad ARM® Cortex®-A53 MPCore™ with CoreSight™	CANbus EBI EMI Ethernet I2C MMC SD SDIO SPI UART USART USB OTG
AMD / Xilinx XCZU11EG-1FFVC1760E	512	DMA WDT	653K+ Logic Cells Zynq®UltraScale+™ FPGA Zynq®UltraScale+™ FPGA 653K+ Logic Cells	653 K	42.5 mm	1760-FCBGA	42.5 mm	1.2 GHz 500 MHz 600 MHz	1760-BBGA FCBGA	FPGA MCU	100 °C	0 °C	256 KB	ARM Mali™-400 MP2 Dual ARM®Cortex™-R5 with CoreSight™ Quad ARM® Cortex®-A53 MPCore™ with CoreSight™	CANbus EBI EMI Ethernet I2C MMC SD SDIO SPI UART USART USB OTG
