YK114 Series
Manufacturer: McGill Microwave Systems
Beta
⌘K
CONN BARRIER STRP 20CIRC 0.433"
| Part | Terminal Screw Finish | Mounting Type | Terminal Screw Material | Material - Insulation | Operating Temperature (Min) | Operating Temperature (Max) | Material Flammability Rating | Voltage Rating | Terminal Block Type | Features | Barrier Type | Pitch | Bottom Termination | Number of Wire Entries | Top Termination | Number of Circuits | Current Rating | Number of Rows | Wire Gauge (AWG) (Min) | Wire Gauge (AWG) (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 McGill Microwave Systems | Zinc | Chassis Panel Right Angle | Phosphor Bronze | Thermoplastic | -40 °C | 115 °C | UL94 V-0 | 300 VAC/DC | Barrier Block | Flange | 3 Wall (Tri) | 0.433 in | Solder Tab | 20 | Screws with Captive Plate | 20 | 20 A | 1 | 12 AWG | 22 AWG |
McGill Microwave Systems | Zinc | Chassis Panel Right Angle | Steel | Thermoplastic | -40 °C | 115 °C | UL94 V-0 | 300 VAC/DC | Barrier Block | Flange | 3 Wall (Tri) | 0.433 in | Solder Tab | 3 | Screws with Captive Plate | 3 | 20 A | 1 | 12 AWG | 22 AWG |
McGill Microwave Systems | Zinc | Chassis Panel Right Angle | Phosphor Bronze | Thermoplastic | -40 °C | 115 °C | UL94 V-0 | 300 VAC/DC | Barrier Block | Flange | 3 Wall (Tri) | 0.433 in | Solder Tab | 23 | Screws with Captive Plate | 23 | 20 A | 1 | 12 AWG | 22 AWG |
McGill Microwave Systems | Zinc | Chassis Panel Right Angle | Phosphor Bronze | Thermoplastic | -40 °C | 115 °C | UL94 V-0 | 300 VAC/DC | Barrier Block | Flange | 3 Wall (Tri) | 0.433 in | Solder Tab | 18 | Screws with Captive Plate | 18 | 20 A | 1 | 12 AWG | 22 AWG |
McGill Microwave Systems | Zinc | Chassis Panel Right Angle | Phosphor Bronze | Thermoplastic | -40 °C | 115 °C | UL94 V-0 | 300 VAC/DC | Barrier Block | Flange | 3 Wall (Tri) | 0.433 in | Solder Tab | 19 | Screws with Captive Plate | 19 | 20 A | 1 | 12 AWG | 22 AWG |
McGill Microwave Systems | Zinc | Chassis Panel Right Angle | Steel | Thermoplastic | -40 °C | 115 °C | UL94 V-0 | 300 VAC/DC | Barrier Block | Flange | 3 Wall (Tri) | 0.433 in | Solder Tab | 15 | Screws with Captive Plate | 15 | 20 A | 1 | 12 AWG | 22 AWG |
McGill Microwave Systems | Zinc | Chassis Panel Right Angle | Phosphor Bronze | Thermoplastic | -40 °C | 115 °C | UL94 V-0 | 300 VAC/DC | Barrier Block | Flange | 3 Wall (Tri) | 0.433 in | Solder Tab | 25 | Screws with Captive Plate | 25 | 20 A | 1 | 12 AWG | 22 AWG |
McGill Microwave Systems | Zinc | Chassis Panel Right Angle | Phosphor Bronze | Thermoplastic | -40 °C | 115 °C | UL94 V-0 | 300 VAC/DC | Barrier Block | Flange | 3 Wall (Tri) | 0.433 in | Solder Tab | 21 | Screws with Captive Plate | 21 | 20 A | 1 | 12 AWG | 22 AWG |
 McGill Microwave Systems | Zinc | Chassis Panel Right Angle | Steel | Thermoplastic | -40 °C | 115 °C | UL94 V-0 | 300 VAC/DC | Barrier Block | Flange | 3 Wall (Tri) | 0.433 in | Solder Tab | 2 | Screws with Captive Plate | 2 | 20 A | 1 | 12 AWG | 22 AWG |
McGill Microwave Systems | Zinc | Chassis Panel Right Angle | Steel | Thermoplastic | -40 °C | 115 °C | UL94 V-0 | 300 VAC/DC | Barrier Block | Flange | 3 Wall (Tri) | 0.433 in | Solder Tab | 4 | Screws with Captive Plate | 4 | 20 A | 1 | 12 AWG | 22 AWG |
