336503 Series
Manufacturer: McGill Microwave Systems
Beta
⌘K
CBL ASSY U.FL-MCX PL-SCKT 3.937"
| Part | Style | Overall Impedance | Color | Cable Impedance | 2nd Contact Gender | Cable Type | 2nd Connector Mounting Type | 1st Connector Mounting Type | 1st Connector | 2nd Connector Mounting Feature | Features | 1st Contact Gender | Length | 2nd Connector | Frequency - Max | Cable Type Size | Cable Outer Diameter |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 McGill Microwave Systems | AMC to MCX U.FL (UMCC) | 50 Ohms | Copper | 50 Ohms | Female | 178 RG | Panel Mount | Free Hanging (In-Line) | AMC Plug Right Angle U.FL (UMCC) | Bulkhead - Front Side Nut | Shielded | Female | 3.937 in | MCX Socket | |||
McGill Microwave Systems | AMC to MCX U.FL (UMCC) | 50 Ohms | Copper | 50 Ohms | Female | 178 RG | Panel Mount | Free Hanging (In-Line) | AMC Plug Right Angle U.FL (UMCC) | Bulkhead - Front Side Nut | Shielded | Female | 5.906 in | MCX Socket | |||
 McGill Microwave Systems | AMC to MCX U.FL (UMCC) | 50 Ohms | Copper | Female | 1.13mm OD Coaxial Cable Coaxial Cable OD Coaxial Cable | Panel Mount | Free Hanging (In-Line) | AMC Plug Right Angle U.FL (UMCC) | Bulkhead - Front Side Nut | Female | 11.811 in | MCX Socket | 6000 MHz | 1.13 | 1.13 mm | ||
McGill Microwave Systems | AMC to MCX U.FL (UMCC) | 50 Ohms | Copper | 50 Ohms | Female | 178 RG | Panel Mount | Free Hanging (In-Line) | AMC Plug Right Angle U.FL (UMCC) | Bulkhead - Front Side Nut | Shielded | Female | 1.969 in | MCX Socket | |||
 McGill Microwave Systems | AMC to MCX U.FL (UMCC) | 50 Ohms | Black | Female | Coaxial Cable OD Coaxial Cable | Panel Mount | Free Hanging (In-Line) | AMC Plug Right Angle U.FL (UMCC) | Bulkhead - Front Side Nut | Female | 5.906 in | MCX Socket | 1.37 | 1.37 mm | |||
 McGill Microwave Systems | AMC to MCX U.FL (UMCC) | 50 Ohms | Copper | 50 Ohms | Female | 178 RG | Panel Mount | Free Hanging (In-Line) | AMC Plug Right Angle U.FL (UMCC) | Bulkhead - Front Side Nut | Shielded | Female | 9.843 in | MCX Socket | |||
 McGill Microwave Systems | AMC to MCX U.FL (UMCC) | 50 Ohms | Black | Female | Coaxial Cable OD Coaxial Cable | Panel Mount | Free Hanging (In-Line) | AMC Plug Right Angle U.FL (UMCC) | Bulkhead - Front Side Nut | Female | 11.811 in | MCX Socket | 1.37 | 1.37 mm | |||
 McGill Microwave Systems | AMC to MCX U.FL (UMCC) | 50 Ohms | Female | 1.32mm OD Coaxial Cable Coaxial Cable OD Coaxial Cable | Panel Mount | Free Hanging (In-Line) | AMC Plug Right Angle U.FL (UMCC) | Bulkhead - Front Side Nut | Female | 7.874 in | MCX Socket | 1.32 | 1.32 mm | ||||
 McGill Microwave Systems | AMC to MCX U.FL (UMCC) | 50 Ohms | Copper | Female | 1.13mm OD Coaxial Cable Coaxial Cable OD Coaxial Cable | Panel Mount | Free Hanging (In-Line) | AMC Plug Right Angle U.FL (UMCC) | Bulkhead - Front Side Nut | Female | 5.906 in | MCX Socket | 6000 MHz | 1.13 | 1.13 mm | ||
 McGill Microwave Systems | AMC to MCX U.FL (UMCC) | 50 Ohms | Female | 1.32mm OD Coaxial Cable Coaxial Cable OD Coaxial Cable | Panel Mount | Free Hanging (In-Line) | AMC Plug Right Angle U.FL (UMCC) | Bulkhead - Front Side Nut | Female | 1.969 in | MCX Socket | 1.32 | 1.32 mm |
