AD8421 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

3NV /√HZ, LOW POWER INSTRUMENTATION AMPLIFIER

Part	Voltage - Supply Span (Min)	Package Name	Voltage - Supply Span (Max)	Current - Supply	Operating Temperature (Min)	Operating Temperature (Max)	Current - Output / Channel	Number of Circuits	Amplifier Type	Voltage - Input Offset	Package Length	Package Width	Slew Rate	Mounting Type	-3db Bandwidth	Current - Input Bias	Package / Case
Analog Devices Inc./Maxim Integrated AD8421ARZ-RL	5 V	8-SOIC	36 V	2 mA	-40 °C	85 °C	65 mA	1	Instrumentation	60 µV	0.154 in	3.9 mm	35 V/µs	Surface Mount	10 MHz	1 nA
Analog Devices Inc./Maxim Integrated AD8421BRZ-R7	5 V	8-SOIC	36 V	2 mA	-40 °C	85 °C	65 mA	1	Instrumentation	25 µV	0.154 in	3.9 mm	35 V/µs	Surface Mount	10 MHz	100 pA
Analog Devices Inc./Maxim Integrated AD8421BRMZ-R7	5 V	8-MSOP 8-TSSOP 8-MSOP	36 V	2 mA	-40 °C	85 °C	65 mA	1	Instrumentation	25 µV	0.118 in	3 mm	35 V/µs	Surface Mount	10 MHz	100 pA
Analog Devices Inc./Maxim Integrated AD8421ARMZ-R7	5 V	8-MSOP 8-TSSOP 8-MSOP	36 V	2 mA	-40 °C	85 °C	65 mA	1	Instrumentation	60 µV	0.118 in	3 mm	35 V/µs	Surface Mount	10 MHz	1 nA
Analog Devices Inc./Maxim Integrated AD8421ARZ	5 V	8-SOIC	36 V	2 mA	-40 °C	85 °C	65 mA	1	Instrumentation	60 µV	0.154 in	3.9 mm	35 V/µs	Surface Mount	10 MHz	1 nA
Analog Devices Inc./Maxim Integrated AD8421BRZ-RL	5 V	8-SOIC	36 V	2 mA	-40 °C	85 °C	65 mA	1	Instrumentation	25 µV	0.154 in	3.9 mm	35 V/µs	Surface Mount	10 MHz	100 pA
Analog Devices Inc./Maxim Integrated AD8421ACPZ-RL	5 V	8-LFCSP	36 V	2 mA	-40 °C	125 °C	65 mA	1	Instrumentation	70 µV	3 mm	3 mm	35 V/µs	Surface Mount	10 MHz	1 nA	8-WDFN Exposed Pad CSP
Analog Devices Inc./Maxim Integrated AD8421ACPZ-R7	5 V	8-LFCSP	36 V	2 mA	-40 °C	125 °C	65 mA	1	Instrumentation	70 µV	3 mm	3 mm	35 V/µs	Surface Mount	10 MHz	1 nA	8-WDFN Exposed Pad CSP
