ADM3062E Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

3.0 V TO 5.5 V WITH VIO, ±12 KV IEC ESD PROTECTED, HALF DUPLEX 500 KBPS RS-485 TRANSCEIVER

Part	Number of Drivers	Number of Receivers	Operating Temperature (Min)	Operating Temperature (Max)	Package Width	Package Name	Package Length	Receiver Hysteresis	Protocol	Data Rate	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Mounting Type	Type	Package / Case	Duplex
Analog Devices Inc./Maxim Integrated ADM3062EACPZ-R7	1	1	-40 °C	85 °C	3 mm	10-LFCSP-WD	3 mm	30 mV	RS485	500 kbps	5.5 V	3 V	Surface Mount	Transceiver	10-VFDFN Exposed Pad CSP	Half
Analog Devices Inc./Maxim Integrated ADM3062EBCPZ-R7	1	1	-40 °C	125 °C	3 mm	10-LFCSP-WD	3 mm	30 mV	RS485	500 kbps	5.5 V	3 V	Surface Mount	Transceiver	10-VFDFN Exposed Pad CSP	Half
Analog Devices Inc./Maxim Integrated ADM3062EBCPZ	1	1	-40 °C	125 °C	3 mm	10-LFCSP-WD	3 mm	30 mV	RS485	500 kbps	5.5 V	3 V	Surface Mount	Transceiver	10-VFDFN Exposed Pad CSP	Half
Analog Devices Inc./Maxim Integrated ADM3062EARMZ-R7	1	1	-40 °C	85 °C	3 mm	10-MSOP 10-TFSOP	0.118 in	30 mV	RS485	500 kbps	5.5 V	3 V	Surface Mount	Transceiver		Half
Analog Devices Inc./Maxim Integrated ADM3062EARMZ	1	1	-40 °C	85 °C	3 mm	10-MSOP 10-TFSOP	0.118 in	30 mV	RS485	500 kbps	5.5 V	3 V	Surface Mount	Transceiver		Half
Analog Devices Inc./Maxim Integrated ADM3062EACPZ	1	1	-40 °C	85 °C	3 mm	10-LFCSP-WD	3 mm	30 mV	RS485	500 kbps	5.5 V	3 V	Surface Mount	Transceiver	10-VFDFN Exposed Pad CSP	Half
Analog Devices Inc./Maxim Integrated ADM3062EBRMZ	1	1	-40 °C	125 °C	3 mm	10-MSOP 10-TFSOP	0.118 in	30 mV	RS485	500 kbps	5.5 V	3 V	Surface Mount	Transceiver		Half
Analog Devices Inc./Maxim Integrated ADM3062EBRMZ-R7	1	1	-40 °C	125 °C	3 mm	10-MSOP 10-TFSOP	0.118 in	30 mV	RS485	500 kbps	5.5 V	3 V	Surface Mount	Transceiver		Half
