fakra-generation-3 Series
Manufacturer: McGill Microwave Systems
Beta
⌘K
FAKRA GEN 3 RIGHT ANGLE CRIMP JACK RG-174 RG-188 RG-316 TIMES LMR-100A 50 OHM LOW PROFILE IP67 H KEY CODE
| Part | Contact Termination | Shield Termination | Impedance | Mounting Type | Housing Color | Connector Style | Number of Ports | Ingress Protection Description | Ingress Protection IP Rating | Frequency - Max | Center Contact Material | Fastening Type | Features | Connector Type | Cable Group | Body Material | Center Contact Plating | Operating Temperature (Min) | Operating Temperature (Max) | Dielectric Material | Body Finish | Mating Cycles |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 McGill Microwave Systems | Solder | Crimp | 50 Ohm | Free Hanging (In-Line) Right Angle | Heather Violet | Fakra SMB | 1 | Dust Tight Waterproof | IP67 | 3 GHz | Beryllium Copper | Latch Lock | Code H | Female Socket Jack | 188 316 RG-174 | Zinc Die Cast | Gold | -40 °C | 85 °C | Polytetrafluoroethylene (PTFE) | Tin | 100 cycles |
 McGill Microwave Systems | Crimp | Crimp | 50 Ohm | Free Hanging (In-Line) | Blue Water | Fakra SMB | 1 | 3 GHz | Brass | Snap-On | Code C | Female Socket Jack | 188 188A 316 LMR-100 M17/119-RG174 RG-174 | Zinc Die Cast | Gold | -65 °C | 165 °C | Polytetrafluoroethylene (PTFE) | Tin | 100 cycles | ||
 McGill Microwave Systems | Crimp | Crimp | 50 Ohm | Free Hanging (In-Line) | Claret Violet | Fakra SMB | 1 | 3 GHz | Brass | Latch Lock | Code D | Female Socket Jack | 141 303 58A 58B 58C 9907 Belden B7806A LMR-195 RG-58 |
