ADM7155 Series
Manufacturer: Analog Devices Inc./Maxim Integrated
Beta
⌘K
EVAL BOARD FOR ADM7155CP
| Part | Supplied Contents | Board Type | Contents | Channels per IC (Single) | Channels per IC (Type) | Channels per IC (Count) | Voltage - Input (Minimum) | Voltage - Input (Maximum) | Current - Output | Regulator Type | Utilized IC / Part | PSRR (Maximum) | PSRR (Minimum) | Voltage - Output (Min/Fixed) | Voltage Dropout (Max) | Current - Supply (Max) | Voltage - Output (Max) | Voltage - Input (Max) | Package / Case | Output Configuration | Current - Quiescent (Iq) | Protection Features | Operating Temperature (Max) | Operating Temperature (Min) | Control Features | Mounting Type | Package Length | Package Name | Package Width | Number of Regulators | Output Type | Package Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Analog Devices Inc./Maxim Integrated | Board(s) | Fully Populated | Board | 1 | Single | 1 | 2.3 V | 5.5 V | 600 mA | Positive Adjustable | ADM7155 | |||||||||||||||||||||
 Analog Devices Inc./Maxim Integrated | 600 mA | 92 dB | 65 dB | 1.2 V | 0.21 V | 10 mA | 1.8 V | 5.5 V | 8-WFDFN Exposed Pad CSP | Positive | 7 mA | Over Current Over Temperature | 125 °C | -40 °C | Enable | Surface Mount | 3 mm | 8-LFCSP-WD | 3 mm | 1 | Adjustable | |||||||||||
 Analog Devices Inc./Maxim Integrated | 600 mA | 94 dB | 57 dB | 1.2 V | 0.21 V | 10 mA | 3.4 V | 5.5 V | 8-WFDFN Exposed Pad CSP | Positive | 7 mA | Over Current Over Temperature | 125 °C | -40 °C | Enable | Surface Mount | 3 mm | 8-LFCSP-WD | 3 mm | 1 | Adjustable | |||||||||||
 Analog Devices Inc./Maxim Integrated | 600 mA | 94 dB | 61 dB | 1.2 V | 0.21 V | 10 mA | 2.4 V | 5.5 V | Positive | 7 mA | Over Current Over Temperature | 125 °C | -40 °C | Enable | Surface Mount | 0.154 in | 8-SOIC 8-SOIC-EP | 3.9 mm | 1 | Adjustable | Exposed Pad | |||||||||||
 Analog Devices Inc./Maxim Integrated | 600 mA | 92 dB | 65 dB | 1.2 V | 0.21 V | 10 mA | 1.8 V | 5.5 V | Positive | 7 mA | Over Current Over Temperature | 125 °C | -40 °C | Enable | Surface Mount | 0.154 in | 8-SOIC 8-SOIC-EP | 3.9 mm | 1 | Adjustable | Exposed Pad | |||||||||||
Analog Devices Inc./Maxim Integrated | 600 mA | 94 dB | 57 dB | 1.2 V | 0.21 V | 10 mA | 2.9 V | 5.5 V | Positive | 7 mA | Over Current Over Temperature | 125 °C | -40 °C | Enable | Surface Mount | 0.154 in | 8-SOIC 8-SOIC-EP | 3.9 mm | 1 | Adjustable | Exposed Pad | |||||||||||
Analog Devices Inc./Maxim Integrated | 600 mA | 94 dB | 57 dB | 1.2 V | 0.21 V | 10 mA | 3.4 V | 5.5 V | Positive | 7 mA | Over Current Over Temperature | 125 °C | -40 °C | Enable | Surface Mount | 0.154 in | 8-SOIC 8-SOIC-EP | 3.9 mm | 1 | Adjustable | Exposed Pad | |||||||||||
Analog Devices Inc./Maxim Integrated | 600 mA | 94 dB | 57 dB | 1.2 V | 0.21 V | 10 mA | 2.9 V | 5.5 V | 8-WFDFN Exposed Pad CSP | Positive | 7 mA | Over Current Over Temperature | 125 °C | -40 °C | Enable | Surface Mount | 3 mm | 8-LFCSP-WD | 3 mm | 1 | Adjustable | |||||||||||
Analog Devices Inc./Maxim Integrated | 600 mA | 94 dB | 61 dB | 1.2 V | 0.21 V | 10 mA | 2.4 V | 5.5 V | 8-WFDFN Exposed Pad CSP | Positive | 7 mA | Over Current Over Temperature | 125 °C | -40 °C | Enable | Surface Mount | 3 mm | 8-LFCSP-WD | 3 mm | 1 | Adjustable |
