ADA4304 Series

1:3 Single-Ended, Low Cost, Active RF Splitters

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

1:3 Single-Ended, Low Cost, Active RF Splitters

Part	Package / Case	Frequency (Min)	Frequency (Max)	For Use With/Related Products	Supplied Contents	Type	Utilized IC / Part	Contents	Size / Dimension Width	Size / Dimension Length	Frequency Range 1 (Max)	Frequency Range 1 (Min)
Analog Devices Inc./Maxim Integrated ADA4304-3ACPZ-RL	16-WFQFN Exposed Pad CSP	54 MHz	865 MHz
Analog Devices Inc./Maxim Integrated ADA4304-4ACPZ-R2	16-WFQFN Exposed Pad CSP	54 MHz	865 MHz
Analog Devices Inc./Maxim Integrated ADA4304-4ACPZ-R7	16-WFQFN Exposed Pad CSP	54 MHz	865 MHz
Analog Devices Inc./Maxim Integrated ADA4304-4ACPZ-EB		54 MHz	865 MHz	ADA4304-4	Board(s)	Splitter	ADA4304-4	Board
Analog Devices Inc./Maxim Integrated ADA4304-3ACPZ-R2	16-WFQFN Exposed Pad CSP	54 MHz	865 MHz						0.118 in	0.118 in
Analog Devices Inc./Maxim Integrated ADA4304-2ACPZ-R7	16-WFQFN Exposed Pad CSP										1 GHz	50 MHz
Analog Devices Inc./Maxim Integrated ADA4304-3ACPZ-R7	16-WFQFN Exposed Pad CSP	54 MHz	865 MHz

Catalog

1:3 Single-Ended, Low Cost, Active RF Splitters

Description

The ADA4304-3/ADA4304-4 are 75 Ω active splitters for use in applications where a lossless signal split is required. Typical applications include multituner digital set-top boxes, cable splitter modules, multituners/digital cable ready (DCR) televisions, and home gateways where traditional solutions require discrete passive splitter modules with separate fixed gain amplifiers.The ADA4304-3/ADA4304-4 are fabricated using the Analog Devices, Inc., proprietary silicon germanium (SiGe), complementary bipolar process, enabling them to achieve very low levels of distortion with a noise figure of 4.6 dB. The parts provide low cost alternatives that simplify designs and improve system performance by integrating a signal splitter element and a gain block into a single IC. The ADA4304-3/ADA4304-4 are available in a 16-lead LFCSP and operate in the extended industrial temperature range of −40°C to +85°C.ApplicationsSet-top boxesResidential gatewaysCATV distribution systemsSplitter modulesDigital cable ready (DCR) TVsData Sheet, Rev. 0, 11/07
