AD9219 Series

Catalog

4-CHANNEL QUAD ADC PIPELINED 40MSPS 10-BIT SERIAL 48-PIN LFCSP EP T/R

Part	Package Width	Package Name	Package Length	Voltage - Supply, Analog (Max)	Voltage - Supply, Analog (Min)	Number of A/D Converters	Configuration	Number of Inputs	Reference Type	Operating Temperature (Min)	Operating Temperature (Max)	Ratio - ADC	Ratio - S/H	Number of Bits	Architecture	Features	Voltage - Supply, Digital (Min)	Voltage - Supply, Digital (Max)	Input Type	Sampling Rate (Per Second)	Package / Case	Data Interface	Mounting Type	Supplied Contents	Utilized IC / Part	Contents	Power (Typ)	Input Voltage (Value)
Analog Devices Inc./Maxim Integrated AD9219ABCPZRL7-40	7 mm	48-LFCSP-VQ	7 mm	1.9 V	1.7 V	4 count	S/H-ADC	4	Internal	-40 °C	85 °C	1	1	10 bits	Pipelined	Simultaneous Sampling	1.7 V	1.9 V	Differential Single Ended	40 MHz	48-VFQFN Exposed Pad CSP	LVDS - Serial	Surface Mount
Analog Devices Inc./Maxim Integrated AD9219-65EBZ						4 count								10 bits						40 MHz		Serial		Board(s)	AD9219	Board	378 mW	2 Vpp
Analog Devices Inc./Maxim Integrated AD9219ABCPZ-40	7 mm	48-LFCSP-VQ	7 mm	1.9 V	1.7 V	4 count	S/H-ADC	4	Internal	-40 °C	85 °C	1	1	10 bits	Pipelined	Simultaneous Sampling	1.7 V	1.9 V	Differential Single Ended	40 MHz	48-VFQFN Exposed Pad CSP	LVDS - Serial	Surface Mount
Analog Devices Inc./Maxim Integrated AD9219ABCPZ-65	7 mm	48-LFCSP-VQ	7 mm	1.9 V	1.7 V	4 count	S/H-ADC	4	Internal	-40 °C	85 °C	1	1	10 bits	Pipelined	Simultaneous Sampling	1.7 V	1.9 V	Differential Single Ended	65 MHz	48-VFQFN Exposed Pad CSP	LVDS - Serial	Surface Mount
