VDRS Series

Catalog

VARISTORS VDR ST 07D 1200A 095V STLDS TAPE E3

Part	Current - Surge	Varistor Voltage (Typ)	Maximum AC Volts	Operating Temperature (Max)	Operating Temperature (Min)	Capacitance	Varistor Voltage (Min)	Package Name	Package Diameter	Maximum DC Voltage	Mounting Type	Varistor Voltage (Max)	Energy	Number of Circuits
Vishay Dale VDRS07H095TSE
Vishay Dale VDRS20W300BSE	6.5 kA	470 V	300 V	85 °C	-40 °C	810 pF	423 V	Disc	22.5 mm	385 V	Through Hole	517 V	280 J	1
Vishay Dale VDRS07B030BSE	250 A	47 V	30 V	85 °C	-40 °C	1600 pF	42.3 V	Disc	9 mm	38 V	Through Hole	51.7 V	3.6 J	1
Vishay Dale VDRS14T385TSE
Vishay Dale VDRS07H095TME
Vishay Dale VDRS20W625BSE	6.5 kA	1000 V	625 V	85 °C	-40 °C	320 pF	900 V	Disc	23 mm	825 V	Through Hole	1.1 kV	448 J	1
Vishay Dale VDRS05C060BSE	400 A	100 V	60 V	85 °C	-40 °C	290 pF	90 V	Disc	7 mm	85 V	Through Hole	110 V	2.9 J	1
Vishay Dale VDRS05A040BSE	100 A	68 V	40 V	85 °C	-40 °C	460 pF	61.2 V	Disc	7 mm	56 V	Through Hole	74.8 V	1.6 J	1
Vishay Dale VDRS14T550TSE	4.5 kA	910 V	550 V	85 °C	-40 °C	180 pF	819 V	Disc	16.5 mm	745 V	Through Hole	1.001 kV	160 J	1
Vishay Dale VDRS10P140BSE	2500 A	220 V	140 V	85 °C	-40 °C	540 pF	198 V	Disc	12 mm	180 V	Through Hole	242 V	33 J	1
